Cisco UCSX-M2-240G-D | UCS X-Series 240GB M.2 SATA Boot SSD, Micron G2
SKU:UCSX-M2-240G-D
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 240GB M.2 SATA SSD is a Micron G2 boot drive for Cisco UCS X-Series compute nodes, specifically the UCS X210c M7. It is intended as a dedicated operating system boot device for Windows or Linux and hypervisor deployments, and it replaces the earlier G1 part UCSX-M2-240GB-D.
The drive installs on the UCSX-M2-HWRD-FPS boot-optimised M.2 RAID controller, which supports RAID 1 mirroring or JBOD and accepts up to two matching M.2 SATA SSDs. The controller is available only with 240GB, 480GB and 960GB M.2 SATA modules, and this 240GB capacity is the entry option in that range, alongside the 480GB UCSX-M2-480G-D and 960GB UCSX-M2-960G-D.
Boot is UEFI only, and legacy boot is not supported. Cisco recommends M.2 SATA SSDs be used as boot-only devices. The controller and installed drives can be configured and monitored through Cisco Intersight Managed Mode. Drives are not hot-pluggable, so the compute node must be powered off to replace them.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Boot-optimised local storage for Cisco UCS X210c M7 compute nodes
- Hardware RAID 1 mirroring across two M.2 SATA modules via the boot-optimised RAID controller
- JBOD mode supported for independent boot drives
- Configuration and monitoring through Cisco Intersight Managed Mode
- Enterprise-class Micron G2 SSD sourced and qualified by Cisco
- UEFI boot support for Windows and Linux operating systems
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCSX-M2-240G-D
- Description: 240GB 2.5in M.2 SATA Micron G2 SSD
- Capacity: 240GB
- Interface: M.2 SATA, 6Gb/s
- M.2 card length: 80 mm
- Generation: G2 (Micron), replaces G1 part UCSX-M2-240GB-D
- Controller: UCSX-M2-HWRD-FPS boot-optimised M.2 RAID controller
- RAID support: RAID 1 and JBOD
- Quantity per controller: up to two matching M.2 SATA SSDs
- Boot mode: UEFI only, legacy boot not supported
- Recommended use: boot-only device
- Hot-plug: not supported, compute node must be powered off to replace
- Management: Cisco Intersight Managed Mode
- OS support: Windows and Linux
- Spare part PID: UCSX-M2-240G-D=
- Sibling PIDs: UCSX-M2-480G-D (480GB), UCSX-M2-960G-D (960GB)
FAQs
Q: Does this SSD need a licence?
A: No licence is required for the drive itself. Management of the boot-optimised controller and drives is supported through Cisco Intersight Managed Mode.
Q: Which Cisco server does it work with?
A: It is designed for the Cisco UCS X210c M7 Compute Node, installed in a UCS X9508 chassis. It requires the UCSX-M2-HWRD-FPS boot-optimised M.2 SATA RAID controller.
Q: Can I mirror two of these drives?
A: Yes. The UCSX-M2-HWRD-FPS controller supports RAID 1 or JBOD with up to two matching M.2 SATA SSDs, available with 240GB, 480GB and 960GB modules.
Q: Does it support legacy BIOS boot or hot-swapping?
A: No. Boot is UEFI only and hot-plug is not supported, so the compute node must be powered off before the drive is replaced.
Q: How does the 240GB model differ from the other capacities?
A: The 240GB UCSX-M2-240G-D is the smallest option, with the 480GB UCSX-M2-480G-D and 960GB UCSX-M2-960G-D offering more capacity for the same controller.
