Cisco UCSX-CPU-I8558 | Xeon Platinum 8558 CPU, 48-Core 2.1GHz, 330W, 2S
SKU:UCSX-CPU-I8558
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Intel Xeon Platinum 8558 is a 5th Gen Intel Xeon Scalable processor supplied as a CPU option for the Cisco UCS X210c M7 compute node in the UCS X-Series modular system. It is a 2S Mainline part aimed at balanced, general-purpose virtualisation and enterprise workloads.
This variant provides 48 cores at a 2.1GHz base clock with 260MB of cache and a 330W TDP. It supports DDR5 memory at up to 5200 MT/s and offers up to 4 UPI links at 20 GT/s, so it can be used in a two-CPU configuration, including two of this processor. On the X210c M7 it pairs with the Intel C741 series chipset, with 8 memory channels per CPU and up to 2 DIMMs per channel.
The processor is installed in the UCS X210c M7, which mounts in the UCS X9508 chassis. Matching heat sinks for the front and rear CPU positions are UCSX-C-M7-HS-F and UCSX-C-M7-HS-R. Although the platform lists DDR5 DIMMs up to 5600 MT/s, this CPU runs memory at up to 5200 MT/s.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 5th Gen Intel Xeon Scalable processor with 48 cores and 260MB cache
- 2S Mainline segment CPU suited to balanced general-purpose workloads
- Supports DDR5 memory at up to 5200 MT/s
- Paired with the Intel C741 series chipset on the UCS X210c M7
- Up to 4 UPI links at 20 GT/s for two-socket configurations
- Can be installed in a 2-CPU configuration, unlike the 1-socket U parts
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Processor: Intel Xeon Platinum 8558 (5th Gen Intel Xeon Scalable)
- Processor series: Intel Xeon 8000 Series
- Segment: 2S Mainline
- Cores: 48
- Clock frequency: 2.10 GHz
- Power (TDP): 330 W
- Cache size: 260 MB
- Maximum sockets: 2S
- Highest DDR5 DIMM clock support: 5200 MT/s
- Memory channels: 8 per CPU, up to 2 DIMMs per channel
- Memory type (X210c M7): DDR5 RDIMM, 1.1 V
- UPI links: up to 4 at 20 GT/s
- Chipset pairing (X210c M7): Intel C741 series
- Cisco description: Intel I8558 2GHz/330W 48C/260MB DDR5 5200MT/s
FAQs
Q: Which Cisco compute node does this CPU fit?
A: It is an orderable CPU for the Cisco UCS X210c M7 Compute Node, which mounts in the UCS X9508 chassis.
Q: Can I run two of these CPUs in one node?
A: Yes. This is a 2S Mainline part and can be used in a two-CPU configuration, including two of this processor.
Q: What memory speed does it support?
A: The CPU supports DDR5 at up to 5200 MT/s. The X210c M7 platform lists DIMMs up to 5600 MT/s, but this processor is limited to 5200 MT/s.
Q: Which heat sink does it need?
A: The X210c M7 uses UCSX-C-M7-HS-F for the front CPU position and UCSX-C-M7-HS-R for the rear position. Thermal paste (UCSX-CPU-TIM=) and the CPU assembly tool (UCSX-CPUAT=) are also listed.
Q: Does the CPU need its own power supply?
A: No. It has a 330W TDP, and node and chassis power comes from the UCS X9508 chassis power supplies.
