Cisco UCSX-CPU-I6745P | UCS X-Series Xeon 6745P CPU, 32 Cores, 3.1GHz, 300W
SKU:UCSX-CPU-I6745P
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Xeon 6745P is a performance-segment Intel Xeon 6 Scalable processor (Granite Rapids-SP, P-core) ordered as a CPU option for Cisco UCS X-Series M8 compute nodes, such as the UCS X210c M8. It suits virtualisation, scale-out and enterprise workloads that benefit from higher clock speeds with a moderate core count.
This variant provides 32 P-cores at 3.10 GHz with a 300 W TDP and 336 MB of cache. Each CPU offers eight DDR5 memory channels with up to two DIMMs per channel, running at up to 6400 MT/s at one DIMM per channel and up to 5200 MT/s at two DIMMs per channel. On the X210c M8 platform it supports up to four UPI links at 24 GT/s, and a two-socket node can scale to 8 TB of memory using 32 x 256 GB DDR5 DIMMs.
It installs in the Cisco UCS X210c M8 Compute Node, which sits in the UCS X9508 chassis, and is also listed for the HCIXVS210c M8 vSAN ReadyNode. Two-CPU configurations must use two identical CPUs. No licence is required for the CPU itself, and the platform is managed through Cisco Intersight.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Intel Xeon 6 Scalable P-core processor for the UCS X210c M8 compute node
- Supports one-CPU or two-CPU configurations using identical CPUs
- Eight DDR5 memory channels per CPU with up to 2 DIMMs per channel
- Up to 8 TB of memory per node (32 x 256 GB DDR5) in a two-socket configuration
- Up to four UPI links at 24 GT/s on the platform
- Higher-clock, lower-core-count option for performance-oriented workloads
- Managed through the Cisco Intersight cloud operations platform
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCSX-CPU-I6745P
- Processor: Intel Xeon 6745P
- Generation: Intel Xeon 6 (6th Generation), GNR-SP High Tier
- Core architecture: P-Core
- Cores: 32
- Clock frequency: 3.10 GHz
- Power (TDP): 300 W
- Cache size: 336 MB
- Segment: Performance
- Maximum sockets: 2S (1 or 2 CPUs supported)
- Memory type: DDR5 RDIMM
- Highest DDR5 DIMM clock: 6400 MT/s
- Memory channels per CPU (X210c M8): 8, up to 2 DIMMs per channel
- DDR5 speed (X210c M8): up to 6400 MT/s at 1DPC, up to 5200 MT/s at 2DPC
- UPI links (X210c M8 platform): up to 4 at 24 GT/s
- Compatible compute node: Cisco UCS X210c M8
FAQs
Q: Does this CPU need a licence?
A: No licence is required for the CPU itself. The UCS X-Series platform is managed through Cisco Intersight, which has its own subscription tiers.
Q: Which Cisco systems is this CPU used in?
A: It is a CPU option for the Cisco UCS X210c M8 Compute Node, which installs in the UCS X9508 chassis. It is also listed for the HCIXVS210c M8 vSAN ReadyNode.
Q: Can I run two of these CPUs in one node?
A: Yes, it supports one-CPU or two-CPU configurations. A two-CPU node must use two identical CPUs, and two CPUs are required when using UCS X-Series X-Fabric and PCIe nodes.
Q: What memory does it support?
A: It supports DDR5 RDIMM from 16GB to 256GB, with eight memory channels per CPU. Speeds reach 6400 MT/s at one DIMM per channel and 5200 MT/s at two DIMMs per channel on the X210c M8.
Q: What are the thermal limits to be aware of?
A: The CPU has a 300 W TDP. The X210c M8 specification limits normal operating temperature to 35 C, lowered to 28 C if there is a fan fault.
