Cisco

Cisco UCSX-CPU-I5420+ | Xeon Gold 5420+ 28-Core 2.0GHz 205W CPU, UCS X210c M7

SKU:UCSX-CPU-I5420+

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCSX-CPU-I5420+ is a 4th Gen Intel Xeon Scalable (Sapphire Rapids) processor for the Cisco UCS X210c M7 Compute Node. It is positioned as a 2-socket mainline CPU, suited to general-purpose compute workloads in Cisco UCS X-Series modular systems managed through Cisco Intersight.

The processor has 28 cores running at 2.0GHz with 52.5MB of cache and a 205W TDP. The DDR5 memory rating is up to 4400MT/s. The '+' suffix marks a Feature Plus SKU that enables one instance each of the DSA, IAA, QAT and DLB embedded accelerators. Each CPU provides 8 memory channels with up to 2 DIMMs per channel, and up to 4 UPI links at 16GT/s.

It is selectable as an available 4th Gen Intel Xeon Scalable CPU on the UCS X210c M7, which mounts in the UCS X9508 chassis. The node can be configured with one CPU, or with two identical CPUs. The processor itself needs no licence.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 4th Gen Intel Xeon Scalable architecture with built-in accelerators
- Feature Plus SKU enables 1 instance each of DSA, IAA, QAT and DLB accelerators
- DDR5 memory support with up to 8 channels per CPU
- Supports 1-CPU or 2-CPU configurations in the UCS X210c M7
- Up to 4 UPI links at 16 GT/s for dual-socket communication
- Works with Cisco Intersight Managed Mode and UCSM Managed Mode

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID: UCSX-CPU-I5420+
- Spare PID: UCSX-CPU-I5420+=
- Processor family: 4th Gen Intel Xeon Scalable, 5000 Series
- Segment: 2S Mainline, maximum 2 sockets
- Cores: 28
- Clock frequency: 2.00 GHz
- Power (TDP): 205 W
- Cache size: 52.50 MB
- Highest DDR5 DIMM clock support: 4400 MT/s
- DDR5 speed on X210c M7: up to 4800 MT/s at 1DPC, up to 4400 MT/s at 2DPC
- Memory channels: 8 per CPU, up to 2 DIMMs per channel (16 DIMMs per CPU)
- UPI links: up to 4 at 16 GT/s
- Embedded accelerators: 1 instance each of DSA, IAA, QAT and DLB
- Chipset on X210c M7: Intel C741 series
- Host node: Cisco UCS X210c M7 Compute Node (UCSX-210C-M7)
- CPU configuration: 1 CPU, or 2 identical CPUs

FAQs

Q: Does this processor need a licence?
A: No licence is needed for the processor itself. The host UCS X210c M7 is managed through Cisco Intersight, which carries its own licence or subscription.

Q: Which server node does it fit?
A: It is a CPU option for the Cisco UCS X210c M7 Compute Node, which mounts in the UCS X9508 chassis.

Q: Can I run two of these in one node?
A: Yes. The X210c M7 supports one CPU or two CPUs, and a dual-CPU configuration requires two identical processors.

Q: What power does it draw?
A: The CPU has a 205W TDP. The X210c M7 node has no power supply of its own and is powered from the UCS X9508 chassis power supplies.

Q: What does the plus suffix mean?
A: The plus suffix denotes a Feature Plus SKU, which enables one instance each of the DSA, IAA, QAT and DLB embedded accelerators.
