Cisco UCSX-CPU-I5318N | UCS X-Series Xeon Gold 5318N 24-Core 2.1GHz 150W CPU

SKU:UCSX-CPU-I5318N

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Xeon Gold 5318N is a 3rd Gen Intel Xeon Scalable (Ice Lake) processor for the Cisco UCS X-Series modular system. It is a networking-optimised part, built for telecom and network function workloads such as L3 forwarding, 5G UPF, OVS DPDK, VPP FIB router, VPP IPsec, NGINX web serving, vEPC, vBNG and vCMTS.

The processor has 24 cores at a 2.1 GHz base clock with 36 MB of cache and a 150 W TDP. The N suffix means a higher base frequency at a lower TDP than comparable parts, which gives better performance per watt. Three UPI links at 11.2 GT/s connect the sockets in dual-socket configurations, and DDR4 memory runs at up to 2666 MHz. Intel Optane Persistent Memory is supported, and both CPU sockets must be populated to use it.

This CPU is orderable for the Cisco UCS X210c M6 Compute Node, which mounts in a UCS X9508 chassis and takes one or two CPUs. The platform provides 32 DIMM slots in total, 16 per CPU. A CPU heat sink (UCSX-C-M6-HS-F for the front socket, UCSX-C-M6-HS-R for the rear socket) and thermal interface material (UCSX-CPU-TIM) are required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Networking-optimised N-suffix part with higher base frequency at lower TDP for better performance per watt
- Suited to L3 forwarding, 5G UPF, OVS DPDK, VPP, vEPC, vBNG and vCMTS workloads
- Supports Intel Optane Persistent Memory (PMem), which requires both CPU sockets to be populated
- 3 UPI links at 11.2 GT/s for dual-socket configurations
- Orderable for the Cisco UCS X210c M6 Compute Node in a UCS X9508 chassis
- 24 cores and 36 MB cache for dense, multi-threaded network workloads

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Processor: Intel Xeon Gold 5318N (5000 Series, 3rd Gen Xeon Scalable, Ice Lake)
- Cores: 24
- Clock frequency: 2.1 GHz
- Power (TDP): 150 W
- Cache size: 36 MB
- UPI links: 3 at 11.2 GT/s
- Highest DDR4 DIMM clock support: 2666 MHz
- Intel Optane PMem support: Yes
- CPU suffix N: Networking optimised, with higher base frequency and lower TDP for best performance per watt
- Supported node: Cisco UCS X210c M6 Compute Node (one or two CPUs per node)
- Chassis: Cisco UCS X9508 (7RU, up to 8 compute nodes)
- Spare PID: UCSX-CPU-I5318N=
- Required heat sinks: UCSX-C-M6-HS-F (front socket), UCSX-C-M6-HS-R (rear socket)
- Thermal interface material: UCSX-CPU-TIM

FAQs

Q: Which compute node does this CPU fit?
A: It is orderable for the Cisco UCS X210c M6 Compute Node, which mounts in a Cisco UCS X9508 chassis. The node takes one or two 3rd Gen Intel Xeon Scalable CPUs.

Q: What else is needed to install it?
A: Each CPU needs a heat sink, UCSX-C-M6-HS-F for the front socket or UCSX-C-M6-HS-R for the rear socket, plus thermal interface material (UCSX-CPU-TIM).

Q: What memory speed does it support?
A: DDR4 DIMMs run at up to 2666 MHz with this CPU. If a faster DIMM is installed, it is clocked down to the lowest common speed of CPU and DIMM.

Q: What does the N suffix mean?
A: N denotes a networking-optimised Xeon, with a higher base frequency and lower TDP for the best performance per watt in workloads such as L3 forwarding, 5G UPF, OVS DPDK and VPP.

Q: Does it support Intel Optane Persistent Memory?
A: Yes. Optane PMem is supported, and both CPU sockets in the node must be populated to use it.
