Cisco

Cisco UCSX-CPU-I5317 | UCS X-Series Xeon Gold 5317 12-Core 3.0GHz CPU, 150W

SKU:UCSX-CPU-I5317

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Intel Xeon Gold 5317 is a 3rd Gen Intel Xeon Scalable (Ice Lake) processor for the Cisco UCS X210c M6 Compute Node in the UCS X-Series Modular System. It suits general-purpose, virtualisation and scale-out enterprise workloads managed through Cisco Intersight or UCS Manager.

The processor has 12 cores running at a 3.0GHz base clock, 18MB of cache and a 150W TDP. It provides 3 UPI links at 11.2 GT/s and supports DDR4 memory up to 2933MHz. Intel Optane Persistent Memory is supported, and each X210c M6 node takes one or two identical CPUs. No licence is required for the CPU itself.

It installs in the Cisco UCS X210c M6 Compute Node, which sits in the UCS X9508 chassis. Adding a CPU requires heat sink UCSX-C-M6-HS-F= for the front socket or UCSX-C-M6-HS-R= for the rear socket, plus CPU assembly tool UCSX-CPUAT= and thermal interface material UCSX-CPU-TIM=. It works with 3200MHz DDR4 RDIMM and LRDIMM, which clock down to 2933MHz with this CPU.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 3rd Gen Intel Xeon Scalable (Ice Lake) processor for the Cisco UCS X210c M6 Compute Node
- Supports Intel Optane Persistent Memory in App Direct and Memory modes
- Mixed DIMM and PMem configurations require two identical CPUs
- 3200MHz DDR4 DIMMs run at 2933MHz with this CPU
- Supported in Intersight Managed Mode and UCSM Managed Mode configurations
- Eight memory channels per CPU with up to two DIMMs per channel

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID (PID): UCSX-CPU-I5317
- Processor: Intel Xeon Gold 5317, 3rd Gen Intel Xeon Scalable (Ice Lake)
- Processor series: 5000 Series
- Cores: 12
- Clock frequency: 3.0GHz
- Cache size: 18MB
- Power (TDP): 150W
- UPI links: 3 at 11.2 GT/s
- Highest DDR4 DIMM clock support: 2933MHz
- Intel Optane PMem support: Yes
- Compatible chipset (X210c M6): Intel C621A series
- Memory channels per CPU (X210c M6): 8 channels, up to 2 DIMMs per channel
- CPU configuration (X210c M6): 1 or 2 identical CPUs per node
- Spare part PID: UCSX-CPU-I5317=

FAQs

Q: Does this CPU need a licence?
A: No licence is required for the CPU itself. Operating system and virtualisation software such as Windows Server, RHEL, SUSE or VMware is ordered separately.

Q: Which Cisco server does this processor fit?
A: It is a CPU option for the Cisco UCS X210c M6 Compute Node, which installs in the UCS X9508 chassis. Each node takes one or two identical CPUs.

Q: What else is needed to install it?
A: When adding a CPU you need heat sink UCSX-C-M6-HS-F= for the front socket or UCSX-C-M6-HS-R= for the rear socket. You also need CPU assembly tool UCSX-CPUAT= and thermal interface material UCSX-CPU-TIM=.

Q: What memory speed does it support?
A: It supports DDR4 up to 2933MHz. 3200MHz DDR4 RDIMM and LRDIMM modules are supported and run at 2933MHz with this CPU.

Q: Does it support Intel Optane Persistent Memory?
A: Yes. It supports Intel Optane PMem 128GB, 256GB and 512GB modules. Mixed DIMM and PMem configurations require two identical CPUs in the node.

Q: What power does it draw?
A: The TDP is 150W. It is powered through the UCS X9508 chassis power supplies, and the X210c M6 node has a 1300W maximum power cap for all component combinations.
