Cisco UCSX-CPU-I4514Y | Xeon Silver 4514Y 16-Core CPU, 2.0GHz, 150W, 30MB
SKU:UCSX-CPU-I4514Y
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Intel Xeon Silver 4514Y is a 5th Gen Intel Xeon Scalable processor from the 4000 series, ordered as a CPU option for Cisco UCS X-Series M7 compute nodes. It is a 2-socket capable Mainline part aimed at general-purpose virtualisation and enterprise workloads on UCS X210c M7 nodes in a UCS X9508 chassis.
The processor has 16 cores running at 2.00 GHz with a 150 W TDP and 30 MB of cache. It supports DDR5 memory at up to 4400 MT/s. The Y suffix marks a general SKU with Intel Speed Select Technology - Performance Profile (SST-PP) enabled. It pairs with the Intel C741 series chipset on the UCS X210c M7.
One CPU, or two identical CPUs, can be selected per compute node. It is listed in the Cisco UCS X210c M7 Compute Node spec sheet for 5th Gen Intel Xeon Scalable CPUs, and is supported in configurations with DRAM, NVMe PCIe drives and GPUs.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Mainline 2-socket CPU option for Cisco UCS X-Series M7 compute nodes
- One CPU, or two identical CPUs, can be selected per compute node
- Y suffix: Intel Speed Select Technology - Performance Profile (SST-PP) enabled
- DDR5 memory support with on-die ECC RDIMMs
- Pairs with the Intel C741 series chipset on the UCS X210c M7
- Supported in configurations with DRAM, NVMe PCIe drives and GPUs
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Processor: Intel I4514Y (Xeon Silver 4514Y)
- Processor family: 5th Gen Intel Xeon Scalable (4000 Series)
- Segment: 2S Mainline
- Maximum sockets: 2
- Cores: 16
- Clock frequency: 2.00 GHz
- Power (TDP): 150 W
- Cache size: 30 MB
- Highest DDR5 DIMM clock support: 4400 MT/s
- Memory type (platform): DDR5 RDIMM, 1.1 V, 8 channels per CPU, up to 2 DIMMs per channel
- Chipset (platform): Intel C741 series
- UPI links (platform): up to 4 at 20 GT/s
- Suffix Y: general SKU with SST-PP enabled
- Spare PID: UCSX-CPU-I4514Y=
FAQs
Q: Which Cisco compute node is this CPU used in?
A: It is listed as a 5th Gen Intel Xeon Scalable CPU option for the Cisco UCS X210c M7 Compute Node, which installs in a UCS X9508 chassis.
Q: Can I run two of these in one node?
A: Yes. The Xeon Silver 4514Y is 2-socket capable, but two-CPU configurations require two identical CPUs.
Q: What memory speed does it support?
A: It supports DDR5 memory at up to 4400 MT/s. The platform can reach higher speeds with other processors, but this CPU is limited to 4400 MT/s.
Q: What does the Y suffix mean?
A: The Y suffix denotes a general SKU with Intel Speed Select Technology - Performance Profile (SST-PP) enabled.
Q: What power does this processor draw?
A: It has a 150 W TDP and is powered from the host compute node and the UCS X9508 chassis.
