Cisco UCSX-9508-ACPEM-D | UCS X9508 Rear AC PEM, Hot-Swap Power Module

SKU:UCSX-9508-ACPEM-D

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Rear AC Power Entry Module (PEM) is a hot-swap power module for the Cisco UCS X9508 chassis, part of the UCS X-Series Modular System. It provides the AC input path for the chassis power supplies and suits data-centre and hybrid-cloud modular server deployments built around the 7RU X9508.

The X9508 chassis uses two PEMs for AC inputs: PEM1 feeds power supplies PSU1, PSU2 and PSU3, while PEM2 feeds PSU4, PSU5 and PSU6. The chassis accepts six 2800W Titanium power supplies with 54 VDC output, with AC input at 100 to 127 V AC or 200 to 240 V AC, 50 to 60 Hz, through IEC320 C20 connectors. Chassis-level redundancy modes include Nonredundant, N+1, N+2 and Grid (N+N).

This module is intended for the Cisco UCS X9508 chassis only. The chassis offers eight node slots and four 100mm hot-swappable dual-rotor fans, and is managed through Cisco Intersight.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swap AC power entry module for the UCS X9508 chassis
- Feeds the chassis 2800W Titanium power supplies
- Supports Nonredundant, N+1, N+2 and Grid (N+N) power redundancy at chassis level
- Dual PEM layout splits the six power supplies across two AC input paths
- Midplane-free 7RU chassis design supporting eight node slots
- Chassis managed through Cisco Intersight

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Compatible chassis: Cisco UCS X9508 (7RU, 8 node slots)
- Module type: AC power entry module (PEM), rear, hot-swap
- PEMs per chassis: 2 (PEM1 feeds PSU1, 2, 3; PEM2 feeds PSU4, 5, 6)
- Power supply bays: 6
- Power supplies: 2800W Titanium certified
- Input voltage: 100 to 127 V AC; 200 to 240 V AC
- Input frequency: 50 to 60 Hz
- Maximum input: 3200 VA at 230 VAC
- Output voltage: 54 VDC
- Power connector: IEC320 C20
- Redundancy modes: Nonredundant, N+1, N+2, Grid (N+N)
- Operating temperature: 10 to 35 C
- Non-operating temperature: -40 to 65 C
- Operating humidity: 10% to 90% non-condensing
- Operating altitude: 0 to 3000 m
- Chassis depth: 88.4 cm

FAQs

Q: Which chassis does this power entry module fit?
A: It is designed for the Cisco UCS X9508 chassis, the 7RU modular chassis in the UCS X-Series Modular System.

Q: How many power entry modules does the chassis use?
A: The X9508 uses two AC PEMs. PEM1 supplies power supplies PSU1 to PSU3 and PEM2 supplies PSU4 to PSU6.

Q: What AC input does the chassis accept?
A: The chassis accepts 100 to 127 V AC or 200 to 240 V AC at 50 to 60 Hz through IEC320 C20 connectors. Each 2800W power supply delivers 2800 W at 200 to 240 VAC and 1400 W at 100 to 127 VAC.

Q: Which power redundancy modes are supported?
A: The X9508 chassis supports Nonredundant, N+1, N+2 and Grid (N+N) redundancy modes.

Q: Does this module include the power supplies?
A: No. This is the rear AC power entry module only. The 2800W Titanium power supplies for the chassis are separate parts.
