Cisco UCSC-PSU1-2300WST | UCS C-Series 2300W AC Titanium Power Supply
SKU:UCSC-PSU1-2300WST
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 2300W AC power supply is a hot-swappable module for Cisco UCS C-Series rack servers. It is aimed at high-power server builds with demanding CPU, GPU or storage configurations, and works as a single supply or as one half of a redundant pair.
The unit delivers up to 2300W at 200-240 VAC input and is limited to 1200W at low-line input of 110-127 VAC. It accepts a nominal 100-230 VAC input (90-264 VAC range) at 50-60 Hz, with a 12 VDC main output and 12 VDC standby. Maximum input current is 13A at 100 VAC and maximum input is 2515 VA at 208 VAC. It is built to 80 PLUS Titanium efficiency in the RSP2 form factor, and this WST variant is the Titanium-grade alternative to the standard UCSC-PSU1-2300W.
One power supply is mandatory in the server and a second identical unit can be added for 1+1 redundancy. The IEC320 C20 inlet requires a C19 power cord, and power supply types or wattages should not be mixed within the same server. It is an orderable PSU option for UCS C-Series rack servers such as the C245 M6.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 80 PLUS Titanium efficiency for reduced power losses
- Hot-swappable RSP2 module for UCS C-Series rack servers
- Supports 1+1 redundancy with a second identical power supply
- High 2300W output suited to high-wattage CPU, GPU and storage builds
- Wide-range AC input from 90 to 264 VAC
- 12 VDC main output with 12 VDC standby
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Output power: 2300W at 220-240 VAC input
- Low-line output: limited to 1200W at 110-127 VAC input
- AC input voltage: 100-230 VAC nominal (90-264 VAC range)
- AC input frequency: 50-60 Hz nominal (47-63 Hz range)
- Maximum AC input current: 13A at 100 VAC
- Maximum input volt-amperes: 2515 VA at 208 VAC
- Maximum inrush current: 30A at 35 C
- Maximum hold-up time: 80 ms at 1600W
- Output voltage: 12 VDC
- Standby voltage: 12 VDC
- Efficiency rating: 80 PLUS Titanium
- Form factor: RSP2
- Input connector: IEC320 C20 (C19 power cord required)
- Redundancy: 1+1 with a second identical power supply
FAQs
Q: How much power does it deliver on a standard 110-127 VAC supply?
A: Output is limited to 1200W at low-line input of 110-127 VAC. The full 2300W is available at 220-240 VAC input.
Q: Which power cord does it need?
A: The IEC320 C20 inlet requires a power cord with a C19 connector. 2300W power supplies only fit the 2300W PSU inlet.
Q: Can I run two for redundancy?
A: Yes. One power supply is mandatory and a second identical unit can be added for 1+1 redundancy. Both power supplies in a server must be the same type and wattage.
Q: How does it differ from the UCSC-PSU1-2300W?
A: This WST variant is the 80 PLUS Titanium-grade 2300W AC power supply, while UCSC-PSU1-2300W is its sibling SKU.
Q: Which servers is it used in?
A: It is an orderable PSU option for Cisco UCS C-Series rack servers, for example the C245 M6, and suits high-power configurations.
