Cisco UCSC-PSU1-2300W | UCS C-Series 2300W AC Power Supply, Titanium
SKU:UCSC-PSU1-2300W
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The UCSC-PSU1-2300W is a hot-plug 2300W AC power supply for Cisco UCS C-Series rack servers, rated 80 PLUS Titanium. It is a PSU option for M6-generation servers such as the C220 M6, C240 M6 and C245 M6, and suits GPU-heavy or drive-dense builds in data-centre racks fed by 200-240 VAC.
The module delivers its full 2300W output at 220-240 V input and is derated to 1200W on 110-120 V low-line feeds. It accepts a wide AC range of 90-264 VAC at 50-60 Hz and provides 12 VDC main and 12 VDC standby outputs. One PSU is mandatory, and a second identical unit can be added for 1+1 redundancy. The RSP2 form factor uses an IEC320 C20 inlet, so C19-type power cords are required rather than the cords used with lower-wattage supplies.
Both supplies in a server must be the same type and wattage, so do not mix this module with other PSU ratings in one chassis.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 80 PLUS Titanium efficiency rating
- Hot-swappable design
- Supports 1+1 redundant operation
- Delivers full 2300W at high-line 200-240 VAC input
- Wide-range AC input of 90-264 VAC
- Common PSU option across C220 M6, C240 M6 and C245 M6 servers
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: UCSC-PSU1-2300W
- Maximum output power: 2300W at 220-240 V input
- Low-line output: 1200W at 110-120 V input
- Efficiency rating: 80 PLUS Titanium
- Output voltage: 12 VDC
- Standby voltage: 12 VDC
- AC input voltage: 100-230 VAC nominal (90-264 VAC range)
- AC input frequency: 50-60 Hz nominal (47-63 Hz range)
- Maximum AC input current: 13 A at 100 VAC
- Maximum input volt-amperes: 2515 VA at 208 VAC
- Maximum inrush current: 30 A at 35 C
- Maximum hold-up time: 80 ms at 1600W
- Form factor: RSP2
- Input connector: IEC320 C20
- Redundancy: 1+1 with a second identical PSU
FAQs
Q: Which servers is this power supply used in?
A: It is listed as a PSU option for the Cisco UCS C220 M6, C240 M6 and C245 M6 rack servers.
Q: What power cord does it need?
A: It has an IEC320 C20 inlet and requires C19-type power cords, which differ from the connector used by lower-wattage PSUs.
Q: How much power does it deliver on a 110-120 V feed?
A: Output is derated to 1200W at 110-120 V low-line input. The full 2300W is available at 220-240 V input.
Q: Can I fit it alongside a different wattage PSU for redundancy?
A: No. Both power supplies in a server must be identical, so a redundant pair needs two matching units.
Q: Is it the same part as the UCSC-PSU1-2300W-D?
A: No. The -D suffix is a separate part number used on related M7 and M8 server variants.
