Cisco

Cisco UCSC-PSU1-2300W-D | UCS C-Series 2300W Titanium Hot-Plug Power Supply

SKU:UCSC-PSU1-2300W-D

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco UCS 2300W AC power supply is a hot-plug module for UCS C-Series rack servers such as the C220 M7 and C220 M8. It is built for enterprise data centres where a server needs a dependable, high-efficiency power source, and it carries a Titanium efficiency rating.

The unit delivers a 12 VDC main output with a 12 VDC standby rail. Output is derated by input voltage, with a maximum of 1100 W on 100-120 VAC input and 1200 W on 208-230 VAC input. Maximum input is 1345 VA at 208 VAC, maximum inrush current is 20 A, and hold-up time is 12 ms at 1200 W. One power supply is required in the server, and a second unit can be fitted to provide 1+1 redundancy.

It is listed in the Cisco UCS C220 M7 and C220 M8 installation guides and the C220 M7 SFF spec sheet. Power draw can be sized for a specific server configuration with the Cisco UCS Power Calculator, and standard or jumper power cords connect the supply to the server.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable AC power supply for UCS C-Series rack servers
- Titanium efficiency rating for reduced power loss
- Supports 1+1 redundancy when two units are installed
- 12 VDC main output with 12 VDC standby rail
- Can be sized for a specific server configuration with the Cisco UCS Power Calculator

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Cisco part number: UCSC-PSU1-2300W-D
- Rated power: 2300 W AC
- Efficiency rating: Titanium
- Hot-swappable: Yes
- Output voltage: 12 VDC
- Standby voltage: 12 VDC
- Maximum output power: 1100 W at 100-120 VAC
- Maximum output power: 1200 W at 208-230 VAC
- Maximum input volt-amperes: 1345 VA at 208 VAC
- Maximum inrush current: 20 A
- Maximum hold-up time: 12 ms at 1200 W

FAQs

Q: Which servers is this power supply used in?
A: It is listed in the Cisco UCS C220 M7 and C220 M8 installation guides and the C220 M7 SFF spec sheet. Check the spec sheet for your server model to confirm support.

Q: How much power does it deliver at different input voltages?
A: Output is derated by input voltage. The maximum is 1100 W on 100-120 VAC input and 1200 W on 208-230 VAC input.

Q: Can I run two power supplies for redundancy?
A: Yes. One power supply is required, and a second unit can be installed to provide 1+1 redundancy.

Q: Can I replace it while the server is running?
A: Yes. It is a hot-plug module, so it can be swapped without powering down the server, provided a second power supply is carrying the load.

Q: How do I work out the power my server needs?
A: Use the Cisco UCS Power Calculator to size the supply for your specific server configuration.
