Cisco UCSC-PSU1-1600W | UCS C-Series 1600W AC 200-240V Platinum Power Supply
SKU:UCSC-PSU1-1600W
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a 1600W AC power supply module for Cisco UCS C-Series rack servers. It is built for data centre racks where compute nodes need high wattage or redundant power, such as UCS C-Series M6 servers carrying GPUs or heavy CPU and storage configurations.
The module delivers up to 1600W at 200-240 VAC input, with an accepted range of 180-264 VAC at 47-63 Hz. Outputs are 12 VDC main and 12 VDC standby. It is rated 80 Plus Platinum and Climate Savers Platinum for efficiency, which reduces wasted power and cooling load. Maximum input is 9.5 A and 1250 VA at 200 VAC, and hold-up time is 80 ms at full load. The RSP2 form factor module is hot-swappable and connects through an IEC320 C14 inlet.
It is listed as a power supply option for Cisco UCS C-Series M6 rack servers, such as the UCS C245 M6. It is not rated for 1600W operation on low-line 100-120 VAC feeds, so plan for 200-240 V supply.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Platinum-class efficiency to reduce power waste and cooling load
- Supports redundant 1+1 power supply configurations in supported UCS C-Series servers
- Hot-swappable RSP2 form factor module
- Wide 200-240 VAC input range
- 12 VDC main and standby outputs
- 80 ms hold-up time at full 1600W load
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Maximum output power: 1600W at 200-240 VAC
- AC input voltage: 200-240 VAC nominal (180-264 VAC range)
- AC input frequency: 50 to 60 Hz nominal (47-63 Hz range)
- Maximum AC input current: 9.5 A at 200 VAC
- Maximum input volt-amperes: 1250 VA at 200 VAC
- Maximum inrush current: 30 A at 35 C
- Maximum hold-up time: 80 ms at 1600W
- Output voltage: 12 VDC
- Standby voltage: 12 VDC
- Efficiency rating: 80 Plus Platinum / Climate Savers Platinum
- Form factor: RSP2
- Input connector: IEC320 C14
FAQs
Q: What input voltage does this power supply need?
A: It runs from 200-240 VAC nominal, with an accepted range of 180-264 VAC. It is not rated for 1600W operation on 100-120 VAC feeds.
Q: Which servers does it work with?
A: It is a power supply option for Cisco UCS C-Series M6 rack servers, for example the UCS C245 M6. Check the spec sheet of any other C-Series model against the RSP2 PSU form factor before ordering.
Q: What power cord connector does it use?
A: The inlet is IEC320 C14, so it needs a power cord with a C13 connector suited to your region and PDU.
Q: Can it be used in a redundant configuration?
A: Yes. It supports 1+1 redundant power supply configurations in supported UCS C-Series servers, and the RSP2 module is hot-swappable.
Q: What current does it draw at full load?
A: Maximum input is 9.5 A and 1250 VA at 200 VAC, with a maximum inrush current of 30 A at 35 C.
