Cisco UCSC-PSU-930WDC | UCS C-Series 930W -48V DC Power Supply, Port-Side Intake
SKU:UCSC-PSU-930WDC
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a hot-swappable 930W DC power supply from the Cisco UCS C-Series range, built for installations powered from a -48V to -60V DC feed. It suits DC-powered data centre and telco environments, and it is also listed as a power supply option for Nexus 9300 platform switches, where it is typically fitted as a redundant supply.
The unit is rated at 930W and delivers up to 900W of usable output in -48 to -60V DC deployments. Nominal input is -48V to -60V DC, with a wider -40V to -72V DC minimum to maximum range. Airflow is port-side intake, so it should be paired with fan trays that match that direction. It supports 1+1 redundancy, with up to two supplies per Nexus 9300 switch, and weighs 2.42 lb (1.1 kg).
The Cisco Nexus 9300 datasheet lists this part as N9300 930W DC PS, Port-side Intake. The port-side exhaust 930W DC unit is a different part, UCS-PSU-6332-DC, so check the airflow direction of your chassis before ordering.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable design for 1+1 power redundancy
- Port-side intake airflow, for switches where network cables are wired to the front of the rack
- DC power option alongside the AC and HVAC/HVDC power supplies
- Suited to -48 to -60V DC telco and DC-powered data centre environments
- Wide -40V to -72V DC input range
- Up to 900W usable output in -48 to -60V DC deployments
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: UCSC-PSU-930WDC
- Cisco description: N9300 930W DC PS, Port-side Intake
- Rated power: 930W DC
- Usable power in -48 to -60V DC deployments: 900W
- Nominal input voltage: -48V to -60V DC
- Input voltage range: -40V to -72V DC (min-max)
- Airflow: Port-side intake
- Redundancy: 1+1 hot-swappable, up to 2 supplies per Nexus 9300 switch
- Weight: 2.42 lb (1.1 kg)
- Nexus 9300 chassis operating temperature: 0 to 40 C
- Nexus 9300 chassis storage temperature: -40 to 70 C
- Nexus 9300 chassis humidity: 5 to 95% (noncondensing)
- Nexus 9300 chassis altitude: 0 to 4000 m
FAQs
Q: What input voltage does this power supply need?
A: It runs from a DC feed with a nominal input of -48V to -60V DC, and accepts a wider range of -40V to -72V DC.
Q: How much power does it deliver?
A: It is rated at 930W and provides up to 900W of usable output in -48 to -60V DC deployments.
Q: Which airflow direction does this unit use?
A: It has port-side intake airflow, so use it with fan trays that match that direction. The port-side exhaust 930W DC unit is a separate part, UCS-PSU-6332-DC.
Q: Can I run two of these for redundancy?
A: Yes. It is hot-swappable and supports 1+1 redundancy, with up to two supplies per Nexus 9300 switch.
Q: Which Cisco platforms is it listed for?
A: Cisco lists it as the N9300 930W DC PS, Port-side Intake option in the Nexus 9300 platform switch datasheet. It is also sold under the UCS C-Series name.
