Cisco

Cisco UCSC-PCIE-QD40GF | UCS C-Series Dual-Port 40GbE QSFP+ NIC, QL45412H

SKU:UCSC-PCIE-QD40GF

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCS C-Series QLogic QL45412H is a dual-port 40GbE QSFP+ PCIe network adapter for Cisco UCS C-Series rack servers. It is built on the Cavium/QLogic FastLinQ QL45412HLCU-CI controller and suits virtualised data centres, cloud and service provider deployments, hyperconverged and Azure Stack HCI or Storage Spaces Direct builds, RDMA storage networking and telco NFV workloads.

Each of the two QSFP+ ports runs at a 40 Gbps line rate over optical or DAC connections, and the card uses a low-profile PCIe 3.0 x16 host interface that is backward compatible with Gen2 and Gen1 slots. It supports SR-IOV with up to 240 virtual functions and NPAR with up to 16 physical functions, along with stateless offloads for VXLAN, GENEVE, NVGRE and GRE overlay tunnels. Universal RDMA covers RoCE, RoCEv2 and iSER, and the controller is extensible to iWARP. Jumbo frames up to 9,600 bytes are supported. No licence or subscription is required.

The adapter is supported in Cisco UCS C-Series M4 and M5 and later rack servers, including the C220 M5, C240 M5 and S3260 M5, and in UCS Manager-integrated C-Series systems running UCSM 3.2(2b) or later. It works with standard 40G QSFP+ SR4 optics or 40GBASE-CR4 DAC cables up to 7 m. Check the Cisco UCS Hardware Compatibility List for operating system and driver support.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- SR-IOV and switch-independent NPAR for high-density server virtualisation
- Full offload for VXLAN, GENEVE and NVGRE overlay tunnelling, supporting VMware NSX and Open vSwitch
- Universal RDMA (RoCE, RoCEv2, iSER, extensible to iWARP) for low-latency storage and SMB Direct
- DPDK integration for telco NFV workloads
- OpenStack support with QConvergeConsole management
- Microsoft SDDC-Premium certified for Azure Stack HCI and Storage Spaces Direct (RoCEv2, DCB, VMMQ, SET)
- Management through QLogic Control Suite CLI, QCC PowerKit PowerShell cmdlets and vSphere/ESXCLI plug-ins

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Controller: Cavium/QLogic FastLinQ QL45412HLCU-CI (Cisco QLogic QL45412H)
- Ports: 2 x 40GbE QSFP+ (optical or DAC)
- Line rate: 40 Gbps per port
- Host interface: PCIe Gen3 x16, backward compatible with Gen2 and Gen1
- Host interrupts: INTx and MSI-X
- SR-IOV: up to 240 virtual functions
- NPAR: up to 16 physical functions
- Jumbo frames: up to 9,600 bytes
- Network virtualisation: GRE, NVGRE, VXLAN, GENEVE
- RDMA: RoCE, RoCEv2, iSER, SMB Direct, NVMe over Fabrics, NFSoRDMA
- Stateless offload: IP/TCP/UDP checksum, TSO, LSO, GSO, LRO (Linux), RSC (Windows), RSS, TSS, interrupt coalescing
- Queues: VMware NetQueue, Hyper-V VMQ (up to 512 queues), Linux Multiqueue
- IEEE standards: 40GBASE-CR4, 40GBASE-SR4, 802.3-2012, 802.1Q, 802.1AX, 802.1p, 802.1Qbb (PFC), 802.1Qaz (DCBX/ETS), 802.1Qau, IEEE 1588 PTPv1/PTPv2
- FEC support: FC-FEC
- Boot support: UEFI, PXE, software iSCSI boot (iBFT)
- Form factor: low-profile PCIe card, 6.6 in x 2.54 in, standard-height bracket installed
- Maximum cable distance: 100m OM3 or 150m OM4 MMF, 300m OM3 with enhanced QSFP optics at both ends, 7m DAC
- Operating temperature: 0 to 55 C (32 to 131 F)
- Storage temperature: -20 to 70 C (-4 to 158 F)
- Operating humidity: 10% to 90%
- Storage humidity: 5% to 95%
- Compliance: RoHS compliant, UL 60950-1, CSA C22.2, FCC Class A, AS/NZS Class A

FAQs

Q: Does this adapter need a licence or subscription?
A: No. All advertised hardware features are enabled on the card, although availability of some features depends on driver releases.

Q: Does it need external power?
A: No. The adapter is powered from the host PCIe slot and has no external power connection.

Q: Which Cisco servers is it supported in?
A: It is supported in Cisco UCS C-Series M4 and M5 and later rack servers, such as the C220 M5, C240 M5 and S3260 M5, and in UCS Manager-integrated C-Series systems running UCSM 3.2(2b) or later. Check the Cisco UCS Hardware Compatibility List for operating system and driver support.

Q: What optics and cables does it use?
A: It takes standard 40G QSFP+ SR4 optics or 40GBASE-CR4 DAC cables up to 7 m. Optical reach is 100m on OM3 or 150m on OM4 multimode fibre.

Q: Does it support RDMA?
A: Yes. It supports RoCE, RoCEv2 and iSER, plus SMB Direct, NVMe over Fabrics and NFSoRDMA, and the controller is extensible to iWARP.

Q: Is this a low-profile card?
A: Yes. It is a low-profile PCIe card measuring 6.6 in x 2.54 in, supplied with a standard-height bracket installed.
