Cisco UCSC-PCIE-IQ10GC | UCS C-Series X710-T4 Quad-Port 10GBASE-T NIC

SKU:UCSC-PCIE-IQ10GC

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCS C-Series X710-T4 is a quad-port 10GBASE-T PCIe 3.0 x8 network adapter built on the Intel Ethernet Controller XL710 for Cisco UCS C-Series rack servers. It suits data centre teams moving servers to 10GbE over existing copper cabling in ToR, MoR and EoR layouts, as well as virtualised, NFV and cloud workloads on Intel Xeon based UCS servers.

Four RJ45 ports each auto-negotiate between 10GbE, 1GbE and 100 Mb/s, so the card works with existing 100BASE-T and 1000BASE-T networks while you migrate. 10GBASE-T runs up to 100 m on CAT6A or 55 m on CAT6. The controller supports SR-IOV with 128 virtual functions per device, VMDq for up to 256 VMs, 1,536 Tx and Rx queues, and VxLAN, GENEVE, NVGRE, MPLS and VxLAN-GPE with NSH offloads. Typical power draw is 24.7 W at 10GbE, with a 28.9 W maximum.

Cisco lists the C220 M5, C240 M5, C480 M5 and S3260 M5 servers as supported. This is the server-installed part number UCSC-PCIE-IQ10GC, and the standard OS drivers need no licence or subscription.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Four RJ45 connectors for maximum port density on standard CAT6A cabling
- Auto-negotiates to 1GbE and 100 Mb/s for backwards compatibility with existing networks
- Network virtualisation offloads: VxLAN, GENEVE, NVGRE, MPLS and VxLAN-GPE with NSH
- SR-IOV, VMDq and Intel Ethernet Adaptive Virtual Function for virtualised I/O
- Intel Ethernet Flow Director for hardware-based application traffic steering
- Dynamic Device Personalization for NFV and cloud packet processing
- DPDK optimised for efficient packet processing
- Time Sync support (IEEE 1588, 802.1as)
- PXE and UEFI boot support
- Firmware resiliency with Protect, Detect and Recover

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Ports: 4 x 10GBASE-T RJ45 copper
- Data rate per port: 10GbE, 1GbE and 100 Mb/s with auto-negotiation
- Controller: Intel Ethernet Controller XL710 (X710-T4)
- Host interface: PCIe 3.0 x8 (8 GT/s)
- Cable distance, 10GBASE-T: 55 m on CAT6, 100 m on CAT6A
- Cable distance, 100BASE-T and 1000BASE-T: 100 m on CAT5e, CAT6 or CAT6A
- Queues: 1,536 Tx and Rx queues per device
- SR-IOV: 128 virtual functions per device
- VMDq: up to 256 VMs
- VLAN support: up to 4096 VLAN tags
- Interrupt levels: INTA, MSI, MSI-X
- Power at 10GbE: 24.7 W typical, 28.9 W maximum
- Power at 1GbE: 12.0 W typical, 18.1 W maximum
- Power at 100 Mb/s: 9.2 W typical, 14.9 W maximum
- Dimensions: 167 mm x 69 mm
- Operating temperature: 0 to 55 C
- Storage temperature: -40 to 70 C
- Storage humidity: maximum 90% non-condensing at 35 C
- LED indicators: link and activity; speed LED green for 10Gbps, yellow for 1Gbps, off for 100 Mbps
- Certifications: FCC A, UL, CE, VCCI, BSMI, CTICK, KCC, RoHS compliant

FAQs

Q: Does this adapter need a licence or subscription?
A: No. It operates with standard operating system drivers and needs no licence or subscription.

Q: Which cabling do I need to reach 100 m at 10Gbps?
A: Use CAT6A for 100 m at 10GBASE-T. CAT6 reaches 55 m at 10Gbps. At 1GbE and 100 Mb/s, CAT5e, CAT6 or CAT6A all reach 100 m.

Q: Which Cisco servers support this adapter?
A: Cisco lists the UCS C220 M5, C240 M5, C480 M5 and S3260 M5 servers. Check the Cisco UCS Hardware Compatibility List for current support.

Q: How is the card powered?
A: It draws power from the PCIe slot. Typical consumption is 24.7 W at 10GbE with a 28.9 W maximum, and at voltage and temperature corners it can exceed 25 W and 2.1 A on the 12 V main rail.

Q: How does UCSC-PCIE-IQ10GC differ from UCSC-PCIE-IQ10GC=?
A: They are the same quad-port X710-T4 adapter. UCSC-PCIE-IQ10GC is the server-installed part number and UCSC-PCIE-IQ10GC= is the spare.
