Cisco

Cisco UCSC-P-IQ10GC-D | UCS C-Series Intel X710-T4L 4-Port 10GBASE-T NIC

SKU:UCSC-P-IQ10GC-D

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCS C-Series Intel X710-T4L is a quad-port 10GBASE-T network interface card for Cisco UCS C-Series rack servers. It is built for data centre server connectivity over existing copper cabling, 10GbE migration with 100M and 1G backward compatibility, virtualised and cloud servers, and NFV workloads.

The adapter provides four RJ45 ports that auto-negotiate 10G, 1G and 100M, and connects to the host over PCIe 3.0 x8. 10GBASE-T runs up to 100 m on CAT6A or 55 m on CAT6, while 1000BASE-T and 100BASE-T reach 100 m on CAT5e, CAT6 or CAT6A. It is based on the Intel Ethernet 700 Series controller family and supports SR-IOV with 128 virtual functions per device, VMDq, and VxLAN, NVGRE and GENEVE offloads for virtualised environments. No licence or subscription is required.

It is intended for Cisco UCS C-Series rack servers. Check the Cisco UCS Hardware Compatibility List for the server generation you are deploying. Operating system support follows the Intel Ethernet 700 Series list.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Four RJ45 ports for high port density over standard CAT6A cabling
- Backwards compatible with 100BASE-T and 1000BASE-T networks through autonegotiation
- Network virtualisation offloads including VxLAN, GENEVE, NVGRE, MPLS and VxLAN-GPE with NSH
- Intel Ethernet Flow Director for hardware-based application traffic steering
- Dynamic Device Personalization for efficient NFV and cloud packet processing
- DPDK optimised for efficient packet processing
- SR-IOV, VMDq and Intel Adaptive Virtual Function for virtualised servers
- Platform resiliency with Protect, Detect and Recover firmware protection

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Ports: 4 x 10GBASE-T RJ45
- Port speeds: 10GbE, 1GbE and 100Mb auto-negotiation
- Controller family: Intel Ethernet 700 Series (X710-T4L)
- Host interface: PCIe 3.0 x8 (8 GT/s)
- 10GBASE-T cable reach: 55 m on CAT6, 100 m on CAT6A
- 100BASE-T and 1000BASE-T cable reach: 100 m on CAT5e, CAT6 or CAT6A
- SR-IOV: 128 virtual functions per device
- Queues: 1,536 Tx and Rx queues per device
- VLAN support: up to 4096 VLAN tags
- Interrupt levels: INTA, MSI, MSI-X
- Time synchronisation: IEEE 1588, 802.1as
- Boot and management: PXE, UEFI, SNMP/RMON statistic counters, watchdog timer
- LED indicators: link and activity, link speed colour (green 10Gbps, yellow 1Gbps, off 100Mbps)
- Operating temperature: 0 C to 55 C
- Storage temperature: -40 C to 70 C
- Storage humidity: maximum 90% non-condensing at 35 C
- Physical dimensions: 167 mm x 69 mm
- Hardware certifications: FCC A, UL, CE, VCCI, BSMI, CTICK, KCC
- Compliance: RoHS

FAQs

Q: Does this NIC need a licence or subscription?
A: No. The adapter works without any licence or subscription.

Q: What cabling does it need for 10GBASE-T?
A: Standard copper cabling. 10GBASE-T reaches 100 m on CAT6A or 55 m on CAT6, and 1G and 100M links reach 100 m on CAT5e, CAT6 or CAT6A.

Q: Can it connect to existing 1G or 100M switches?
A: Yes. Each port auto-negotiates 10G, 1G and 100M, so it can connect to older copper network equipment.

Q: Which servers is it designed for?
A: Cisco UCS C-Series rack servers. Check the Cisco UCS Hardware Compatibility List for the server generation you are deploying.

Q: How is the adapter powered?
A: It is powered from the PCIe slot and needs no external power connection. Typical draw rises with link speed, with the highest draw at 10GbE.
