Cisco

Cisco UCSC-P-ID10GC-D | UCS C-Series 2-Port 10GBASE-T RJ45 PCIe HHHL NIC

SKU:UCSC-P-ID10GC-D

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco UCS C-Series 2-port 10GBASE-T network interface card adds 10GbE copper connectivity to Cisco UCS C-Series M7 rack servers. It suits data-centre and enterprise virtualisation or server networking deployments where existing twisted-pair cabling is to be reused.

The card provides two 10GBASE-T RJ45 ports and is built on the Intel X710T2LG controller (Cisco-Intel). It uses a PCIe half-height, half-length (HHHL) form factor with a single-slot bracket, and is listed as a selectable option in Riser 1, 2 or 3 of the UCS C220 M7 Rack Server (SFF). It draws power from the host server PCIe slot, so no separate power supply is needed.

This SKU is the 2-port PCIe HHHL card. The 4-port sibling is UCSC-P-IQ10GC-D, and the OCP 3.0 variant is UCSC-O-ID10GC-D, which is a different form factor and is not interchangeable with this PCIe card. Check the Cisco UCS Hardware and Software Compatibility List for current server and operating system support.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 10GBASE-T RJ45 copper connectivity for reuse of existing twisted-pair cabling
- Dual-port 10GbE NIC option for Cisco UCS C-Series M7 rack servers
- Intel X710-family Ethernet controller
- Half-height, half-length PCIe card for standard half-height riser slots
- Single-slot bracket design
- Orderable as a spare under UCSC-P-ID10GC-D=

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID: UCSC-P-ID10GC-D
- Description: Cisco-Intel X710T2LG 2x10GBE RJ45 PCIe NIC
- Network ports: 2 x 10GBE RJ45 (10GBASE-T)
- Controller: Intel X710T2LG
- Form factor: PCIe card, HHHL (half-height, half-length)
- Bracket: Single-slot (SS)
- Supported riser slots (UCS C220 M7): Riser 1, 2 or 3
- Power: Drawn from the host server PCIe slot
- Spare PID: UCSC-P-ID10GC-D=
- Cisco ordering guide category: 10GbE NICs

FAQs

Q: Which servers is this card listed for?
A: It is listed as a selectable PCIe option card for the Cisco UCS C220 M7 Rack Server (SFF), in Riser 1, 2 or 3. Check the Cisco UCS Hardware and Software Compatibility List for other servers and operating systems.

Q: Does it need a separate power supply?
A: No. The card is powered from the host server PCIe slot.

Q: How does it differ from UCSC-P-IQ10GC-D and UCSC-O-ID10GC-D?
A: UCSC-P-IQ10GC-D is the 4-port PCIe version. UCSC-O-ID10GC-D is the OCP 3.0 form factor and is not interchangeable with this PCIe HHHL card.

Q: What cabling does it use?
A: It has 10GBASE-T RJ45 ports, so it connects over twisted-pair copper cabling and can reuse existing structured cabling.

Q: Is the spare part number different?
A: Yes. The spare PID is UCSC-P-ID10GC-D=.
