Cisco UCSC-NVME-H76801 | UCS NVMe 7.68TB HHHL PCIe SSD, 3 DWPD, HGST SN260
SKU:UCSC-NVME-H76801
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 7.68TB NVMe solid state drive is part of the Cisco UCS NVMe storage family and is built on a Western Digital HGST SN260 device. It is supplied as a Half-Height, Half-Length PCIe add-in card and is designed for UCS C-Series rack and B-Series blade servers running I/O-intensive workloads such as virtualised data centre environments.
The card has a PCIe Gen 3 x4 interface with NVMe 1.2a and is rated at 3 DWPD on a 5-year manufacturer basis. It delivers up to 6100 MBps sequential read and 2230 MBps sequential write, with up to 1240K random read IOPS and 73.2K random write IOPS at 4 KB. Power draw is 25 W active and 8 W idle, supplied through the PCIe slot, and MTBF is rated at 2 million hours.
It is supported in UCS C220 M5 (up to 10), C240 M5 (up to 10), C480 M5 (up to 32), C125 (up to 2) and B200 M5 (up to 2) servers. Western Digital and Intel NVMe drives cannot be mixed in the same server, and an available PCIe slot is required.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- NVMe block storage that integrates transparently with Cisco UCS servers to relieve I/O bottlenecks
- Managed through Cisco UCS Manager and Cisco IMC integration
- 3 DWPD endurance suited to write-intensive enterprise workloads
- PCIe Gen 3 x4 interface with NVMe 1.2a for low-latency access
- HHHL and 2.5-inch SFF devices can be combined in one server when the same partner brand is used
- Supported in UCS C-Series rack and B-Series blade servers
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Capacity: 7680 GB (7.68TB)
- Form factor: Half-Height, Half-Length (HHHL) PCIe add-in card
- Interface: PCIe Gen 3 x4
- NVMe version: 1.2a
- Endurance: 3 DWPD (5-year manufacturer basis)
- Sequential read (64 KB): up to 6100 MBps
- Sequential write (64 KB): up to 2230 MBps
- Random read (4 KB): 1240K IOPS
- Random write (4 KB): 73.2K IOPS
- Random mixed 70/30 (4 KB): 239K IOPS
- Approximate write latency: 20 microseconds
- Power consumption: 25 W active, 8 W idle
- MTBF: 2 million hours
- Device partner: Western Digital (HGST SN260)
- Rack server PID: UCSC-NVME-H76801
- Blade server PID: UCSB-NVME-H76801
FAQs
Q: Which UCS servers support this NVMe card?
A: It is supported in UCS C220 M5 (up to 10), C240 M5 (up to 10), C480 M5 (up to 32) and C125 (up to 2) rack servers, and the B200 M5 blade (up to 2) using the blade PID UCSB-NVME-H76801. The B480 M5 is not supported.
Q: Is this a 2.5-inch U.2 drive or a PCIe card?
A: It is a Half-Height, Half-Length PCIe add-in card, so the server needs a free PCIe slot rather than a 2.5-inch drive bay.
Q: Can I mix it with Intel NVMe drives in the same server?
A: No. Western Digital and Intel NVMe drives cannot be mixed in the same server. HHHL and 2.5-inch devices can be combined if they share the same partner brand.
Q: How much power does it draw?
A: It draws 25 W when active and 8 W at idle, supplied through the PCIe slot, so no separate power connection is needed.
Q: Does it need a licence?
A: No licence is required for the drive itself. It is managed through Cisco UCS Manager and Cisco IMC.
