Cisco UCSC-M-V25-04 | UCS VIC 1467 Quad-Port 10/25G SFP28 mLOM Adapter
SKU:UCSC-M-V25-04
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco UCS Virtual Interface Card (VIC) 1467 is a quad-port SFP28 mLOM network adapter for Cisco UCS C-Series M6 rack servers. It carries 10/25-Gbps Ethernet or FCoE and presents dynamically configurable NIC or HBA interfaces to the host, which suits converged LAN and SAN connectivity, large-scale virtual machine deployments, big data and HPC, and high-bandwidth storage targets and archives.
The card provides four 10/25-Gbps SFP28 ports over a PCIe 3.0 x16 host interface (128 Gb/s) and supports up to 256 virtual interfaces, with roughly eight reserved for internal use. It is built around a Cisco UCS custom ASIC, offers usNIC low-latency operation down to 1 microsecond in back-to-back VIC connections, and delivers over 900,000 IOPS. Maximum power consumption is 25.5 W, drawn from the server's mLOM slot. Management is through UCS Manager, Intersight or standalone Cisco IMC, and no licence or subscription is listed for the adapter.
This variant is the quad-port 10/25G SFP28 mLOM card for the Cisco UCS C220 M6, C240 M6, C225 M6 and C245 M6 servers. It connects to UCS FI 6664, 6652, 6536, 64108, 6454, 6332-16UP and 6332 fabric interconnects and to Nexus switches. It is not supported with UCS-FI-6248 or UCS-FI-6296.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Stateless and agile platform: card personality, interface count and type, MAC/WWN, QoS and failover are set through the service profile
- Up to 256 dynamic virtual adapters and interfaces without requiring SR-IOV support from the OS or hypervisor, while the hardware remains SR-IOV capable
- Cisco SingleConnect carries LAN, SAN and management traffic over one network
- Hardware-based fabric failover provides a redundant path to the Fabric Interconnect
- Stateless offloads for GENEVE, VXLAN and NVGRE
- usNIC and DPDK low-latency kernel bypass, plus VMware NetQueue and Windows VMQ/VMMQ
- RoCEv2, NVMe over Fabrics (RoCEv2) and FC-NVMe support
- Centrally managed through Cisco UCS Manager or Intersight
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: UCSC-M-V25-04
- Product type: Virtual Interface Card, mLOM
- Physical ports: 4x 10/25-Gbps Ethernet and FCoE SFP28
- Speed: 10/25-Gbps per port
- Host interface: PCIe 3.0 x16, 128 Gb/s throughput
- Form factor: mLOM
- Virtual interfaces: 256 (approximately eight reserved for internal use)
- ASIC: Cisco UCS custom Application-Specific Integrated Circuit
- Maximum power consumption: 25.5 W
- Dimensions (L x W x H): 6.26 x 3.99 x 0.74 in (approx. 159 x 101 x 19 mm)
- Supported servers: Cisco UCS C220 M6, C240 M6, C225 M6, C245 M6
- Minimum management release: UCSM 4.2(1) or standalone Cisco IMC 4.2(1)
- Standards: IEEE 802.3x, 802.1q VLAN, 802.1p, 802.1Qaz, 802.1Qbb, prestandard 802.1BR, T11 FCoE, SCSI-FCP
- Jumbo frames: up to 9KB
- Latency: usNIC, as low as 1 microsecond in back-to-back VIC connections
- I/O performance: 900,000+ IOPS
- Lossless Ethernet: Priority Flow Control (PFC)
- Breakout: 4x10G/4x25G to upstream ToR switch with IMC; 4x10G with 6300 series FI; 4x10G/25G with 6400 series FI; 4x25G with 6536 FI
FAQs
Q: Does the UCS VIC 1467 need a licence or subscription?
A: No licence or subscription is listed for this adapter. It is managed through UCS Manager, Intersight or standalone Cisco IMC.
Q: Which servers is UCSC-M-V25-04 compatible with?
A: It is supported in Cisco UCS C220 M6, C240 M6, C225 M6 and C245 M6 rack servers, installed in the mLOM slot.
Q: Which optics and cables can I use with it?
A: Qualified 10G SFP+ optics include SFP-10G-SR, SFP-10G-SR-S, SFP-10G-LR, SFP-10G-LR-S and SFP-10G-T-X. Qualified 25G SFP28 optics include SFP-25G-SR-S, SFP-25G-SL, SFP-10/25G-CSR-S and SFP-10/25G-LR-S. SFP-H25G-CU and SFP-25G-AOC cables are also supported.
Q: Which fabric interconnects and switches does it connect to?
A: It connects to Cisco UCS FI 6664, 6652, 6536, 64108, 6454, 6332-16UP and 6332, and to Nexus 9300, 9200, 5600 and 3000 series switches. It is not supported with the UCS-FI-6248 or UCS-FI-6296 fabric interconnects.
Q: How much power does the adapter draw?
A: Maximum power consumption is 25.5 W, drawn from the host server's mLOM slot.
