Cisco UCSC-9400-8I | UCS C-Series 12G SAS HBA, 8 Internal Ports, 2x SFF-8643
SKU:UCSC-9400-8I
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco UCSC-9400-8I is a 12Gb/s SAS host bus adapter from the UCS C-Series storage adapter range, built on the Broadcom 9400-8i controller. It is a non-RAID HBA designed for UCS C-Series rack servers where the operating system needs direct access to each drive.
It provides 8 internal SAS/SATA ports through two SFF-8643 (x4) mini-SAS HD connectors and connects to the host over a PCIe 3.1 x8 interface. The controller supports 12/6/3 Gb/s SAS and 6/3 Gb/s SATA drives, with up to 1024 SAS/SATA devices per controller. Typical power draw is about 10 W, drawn from the PCIe slot, and no licence or subscription is required.
It suits JBOD and pass-through drive attach for software-defined storage, hyperconverged and other workloads that do not use hardware RAID. It uses internal mini-SAS HD cabling to the drive backplane, and compatibility should be confirmed against the specific UCS server model and firmware.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 12Gb/s SAS and 6Gb/s SATA connectivity for direct-attached drives
- HBA (non-RAID) mode gives the host operating system direct disk access
- Suited to software-defined storage, hyperconverged and JBOD deployments
- SFF-9402 compliant connector pin-out and SFF-8485 SGPIO support
- Lane and polarity reversal with variable PCIe bandwidth negotiation
- Managed with LSA, StorCLI and UEFI HII tools
- Broad operating system support including Windows, VMware ESXi, RHEL, SUSE and Ubuntu
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: SAS host bus adapter (HBA)
- Internal ports: 8 SAS/SATA
- Connectors: 2 x SFF-8643 (x4) internal mini-SAS HD
- SAS speeds: 12/6/3 Gb/s
- SATA speeds: 6/3 Gb/s
- Host interface: PCIe 3.1 x8 (8.0 GT/s per lane)
- Controller: Broadcom SAS3408 I/O controller
- Mode: Non-RAID HBA, JBOD pass-through
- Maximum devices per controller: 1024 SAS/SATA
- Typical power: 10.05 W
- Operating voltage: +12V ±8%, 3.3V ±9%
- Dimensions: 155.65 x 68.90 mm (6.127 x 2.712 in)
- Cable support: Passive copper
- Operating temperature: 0 to 55 C
- Operating humidity: 20 to 80% non-condensing
- Storage temperature: -45 to +105 C
- MTBF (calculated): over 4,500,000 hours at 40 C
- Management tools: LSA, StorCLI, UEFI HII
FAQs
Q: Does this HBA support hardware RAID?
A: No. It is a non-RAID host bus adapter that presents each drive directly to the operating system in JBOD or pass-through mode.
Q: Does it need a licence or subscription?
A: No licence or subscription is required to use this adapter.
Q: How is it powered?
A: It is powered from the PCIe slot (+12V and 3.3V) and draws about 10 W typically, so no separate power cable is needed.
Q: Which servers is it used in?
A: It is intended for Cisco UCS C-Series rack servers. Confirm the server model and firmware in the Cisco UCS Hardware Compatibility List before ordering.
Q: What cabling does it use to connect drives?
A: It uses internal SFF-8643 mini-SAS HD cables from its two x4 connectors to the drive backplane, and passive copper cabling is supported.
