Cisco UCSB-MRAID12G | UCS B-Series M4 12G SAS RAID Controller, 2 Bays, No Cache
SKU:UCSB-MRAID12G
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The FlexStorage 12G SAS RAID controller is a modular storage subsystem for Cisco UCS B-Series M4 blade servers. It combines an LSI SAS 3108 RAID-on-chip controller with integrated drive bays in a single module, giving blades local SAS/SATA boot and data storage with basic RAID protection.
This is the standard iMegaRAID variant with no write cache. It supports RAID 0, RAID 1 and JBOD, with up to 12 Gbps SAS connectivity. Two front-accessible, hot-swappable 2.5-inch SFF bays accept SAS or SATA hard drives and SSDs. The controller is powered from the blade server and needs no separate power supply, and no licence or subscription is required.
It is designed for the Cisco UCS B200 M4 and UCS B420 M4 and is managed through UCS Manager and the UCS B-Series firmware bundles. It does not control NVMe SFF drives. It suits deployments that need simple local mirroring rather than cache or RAID 5/6 workloads such as VSAN, which call for the UCSB-MRAID12G-HE variant.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Integrated RAID controller and drive bays in one FlexStorage module
- LSI SAS 3108 RAID-on-chip with 12 Gbps SAS connectivity
- Hot-swappable front-accessible 2.5-inch HDD and SSD bays
- RAID 0, RAID 1 and JBOD for local boot and data storage on blade servers
- Managed through UCS Manager and UCS B-Series firmware bundles
- No licence or subscription required
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCSB-MRAID12G
- Controller chip: LSI SAS 3108
- Interface speed: up to 12 Gbps SAS
- Drive support: SAS/SATA HDD and SSD, 2.5-inch SFF
- RAID levels: RAID 0, RAID 1 and JBOD
- Software stack: iMegaRAID
- Cache: none
- Drive bays: two hot-swappable 2.5-inch SFF bays, front-accessible
- Form factor: Cisco FlexStorage modular subsystem for UCS B-Series M4 blade servers
- NVMe: NVMe SFF 2.5-inch drives are not controlled by this controller
- Upgrade path: cannot be upgraded to UCSB-MRAID12G-HE
- Power: supplied by the blade server, no separate power supply
FAQs
Q: Does this RAID controller need a licence?
A: No. No licence or subscription is required for the UCSB-MRAID12G.
Q: Which blade servers is it compatible with?
A: It is designed for the Cisco UCS B200 M4 and UCS B420 M4 blade servers. It is managed through UCS Manager and the UCS B-Series firmware bundles.
Q: Does it have cache or support RAID 5 and 6?
A: No. This is the standard iMegaRAID variant with no cache and RAID 0, RAID 1 and JBOD only. Workloads needing cache or RAID 5/6, such as VSAN, are served by the UCSB-MRAID12G-HE variant.
Q: Can it be upgraded to the UCSB-MRAID12G-HE?
A: No. There is no upgrade kit, and the two controllers are not interchangeable on the same module.
Q: Does it support NVMe drives?
A: No. It supports SAS and SATA 2.5-inch drives only, and NVMe SFF drives cannot be controlled by this controller.
