Cisco UCSB-ML-V5Q10G | UCS VIC 15000 Dual-Port 40G mLOM Network Adapter, B200 M6
SKU:UCSB-ML-V5Q10G
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco UCS Virtual Interface Card 15411 is a modular LAN on motherboard (mLOM) network adapter for Cisco UCS B-Series M6 blade servers, part of the UCS VIC 15000 Series. It suits big data and HPC, large-scale virtual machine deployments, high-bandwidth storage targets and NVMe over Fabrics workloads in UCS blade environments.
The card provides two 40-Gbps ports, or four 10-Gbps ports via breakout, with Ethernet and FCoE capability. It supports up to 512 virtual adapters and interfaces and delivers over 900,000 IOPS. Maximum power consumption is 26.9 W, drawn from the blade server through the mLOM slot. With the optional port expander, two 40-Gbps Ethernet ports are enabled.
It connects through UCS fabric interconnects FI 6536, 64108, 6454, 6332-16UP and 6332, and IOMs 2204, 2208, 2304 and 2408, and is built for the UCS B200 M6. The adapter is configured and managed through Cisco UCS Manager or Intersight Managed Mode, with UCSM/IMM 4.2(3) or later and VIC firmware 5.2(3) recommended. No separate licence is required for the adapter.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Stateless and agile design: the service profile dynamically sets the number and type of NICs and HBAs, MAC/WWN, failover, bandwidth and QoS
- Network interface virtualization maps each PCIe interface to an interface on the fabric interconnect
- Cisco SingleConnect carries LAN, SAN and management traffic over one unified network
- Hardware classification engine with stateless offloads for VXLAN, NVGRE and GENEVE
- Low-latency kernel bypass via usNIC and DPDK, with SR-IOV, NetQueue and VMQ/VMMQ support
- NVMe over Fabrics support including NVMe/RoCEv2, NVMe/FC and NVMe/TCP
- Hardware-based fabric failover provides a redundant path to the fabric interconnect
- Consolidates NICs, HBAs, cables and switches to reduce total cost of ownership
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product number: UCSB-ML-V5Q10G
- Description: Cisco UCS VIC 15411 mLOM for Cisco UCS B-Series M6 Blade Server
- Port configuration: Dual-port 40-Gbps or 4x10-Gbps Ethernet/FCoE
- Form factor: Modular LAN on Motherboard (mLOM)
- Virtual adapters and interfaces: 512
- High-performance I/O: Over 900,000 IOPS
- PCI Express: Gen 3 and Gen 4 support
- Power consumption (max): 26.9 W
- Dimensions (L x W x H): 5.85 x 3.4 x 0.94 in
- Components: Cisco UCS custom ASIC
- Jumbo frames: Up to 9KB
- Lossless Ethernet: Priority Flow Control (PFC)
- Network architecture: Redundant path to the fabric interconnect using hardware-based fabric failover
- Supported server: Cisco UCS B200 M6
- Supported fabric interconnects: FI 6536, FI 64108, FI 6454, FI 6332-16UP, FI 6332
- Supported IOMs: 2408, 2304 v1/v2, 2208, 2204
- Recommended software: UCSM/IMM 4.2(3) or later with VIC firmware 5.2(3)
- With optional port expander: Two ports of 40-Gbps Ethernet enabled
FAQs
Q: Does this adapter need a licence?
A: No separate licence is required for the adapter. It is configured and managed through Cisco UCS Manager or Intersight Managed Mode, with UCSM/IMM 4.2(3) or later and VIC firmware 5.2(3) recommended.
Q: Which servers is it compatible with?
A: It fits the mLOM slot of the Cisco UCS B200 M6 blade server. It is not supported on M8 generation servers.
Q: Which fabric interconnects and IOMs does it connect through?
A: It works with UCS fabric interconnects FI 6536, FI 64108, FI 6454, FI 6332-16UP and FI 6332, and with IOMs 2204, 2208, 2304 v1/v2 and 2408.
Q: How is it powered?
A: The card is powered by the blade server through the mLOM slot, with a maximum power consumption of 26.9 W.
Q: How does this SKU differ from other VIC adapters?
A: UCSB-ML-V5Q10G is a dual-port 40G mLOM with 4x10G breakout capability, built for B-Series M6 blade servers. Ethernet and FCoE are supported.
