Cisco UCS-MSTOR-M2 | UCS M.2 SATA Mini Storage Carrier, Pass-Through, Holds 2 Drives

SKU:UCS-MSTOR-M2

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCS-MSTOR-M2 is an internal mini storage carrier module for Cisco UCS C-Series rack servers. It holds up to two M.2 SATA SSDs on a single carrier and is typically used for dedicated operating system or hypervisor boot storage, replacing SD card boot media.

This is the pass-through variant with no RAID control. The drives are presented directly to the operating system, so any mirroring is handled at OS level rather than in CIMC. The carrier takes one or two identical M.2 SATA SSDs, and capacities cannot be mixed. Supported drive PIDs on the Cisco UCS C220 M5 include UCS-M2-I240GB, UCS-M2-I480GB, UCS-M2-240G, UCS-M2-480G and UCS-M2-960G. SATA M.2 drives boot in UEFI mode only, and the server must be powered off to replace drives.

The carrier cannot be combined with SD cards in the same server. It occupies the same server slot as the UCS-M2-HWRAID boot-optimised RAID controller, so only one of the two can be fitted. Choose UCS-M2-HWRAID instead if hardware RAID 1 is required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Holds up to two M.2 SATA SSDs on a single carrier for internal boot storage
- Passes drives through to the operating system with no RAID configuration in CIMC
- Operating system level mirroring can be used for boot drive redundancy
- Suited to boot-only use of M.2 SATA SSDs
- Non-RAID alternative to the UCS-M2-HWRAID boot-optimised RAID controller
- Replaces the SD card module for boot storage

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Part number: UCS-MSTOR-M2
- Description: Mini Storage Carrier for M.2 SATA
- Drive capacity: 1 or 2 M.2 SATA SSDs
- Drive matching: identical M.2 SATA SSDs only, capacities cannot be mixed
- RAID: none, pass-through to the operating system
- Boot mode: UEFI only for SATA M.2 drives, legacy boot not supported
- Hot-plug: not supported, server must be powered off to replace drives
- Power: supplied by the host server internal slot, no separate power supply
- Compatible M.2 SATA SSDs (C220 M5): UCS-M2-I240GB, UCS-M2-I480GB, UCS-M2-240G, UCS-M2-480G, UCS-M2-960G
- Internal drive limit: maximum of six internal SATA drives with two M.2 SATA drives on embedded software RAID
- SD card compatibility: cannot be mixed with SD cards
- Hardware RAID alternative: UCS-M2-HWRAID

FAQs

Q: Does this carrier support hardware RAID?
A: No. The UCS-MSTOR-M2 is a pass-through carrier with no RAID control. Any mirroring must be configured in the operating system. For hardware RAID 1, use the UCS-M2-HWRAID boot-optimised controller instead.

Q: Which M.2 SATA SSDs can be fitted?
A: On the Cisco UCS C220 M5 the supported drives are UCS-M2-I240GB, UCS-M2-I480GB, UCS-M2-240G, UCS-M2-480G and UCS-M2-960G. Fit one or two identical drives, as capacities cannot be mixed.

Q: Can I use it alongside SD cards or the M.2 RAID controller?
A: No. It cannot be mixed with SD cards, and it shares a server slot with UCS-M2-HWRAID, so only one of the two can be fitted per server.

Q: Can the drives be hot-swapped?
A: No. Hot-plug is not supported, so the server must be powered off before replacing the M.2 drives.

Q: What boot mode does it require?
A: SATA M.2 drives on this carrier boot in UEFI mode only. Legacy boot is not supported.
