Cisco UCS-MR-X16G1RTHM | UCS M5 16GB DDR4 2933 MT/s RDIMM, SRx4, Micron-only
SKU:UCS-MR-X16G1RTHM
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 16GB DDR4 registered ECC memory module is built for Cisco UCS M5 rack and blade servers and the matching HyperFlex HX M5 nodes. It suits memory upgrades and spares for virtualisation, database and general data-centre workloads.
The module runs at up to 2933 MT/s (PC4-23400), depending on the CPU memory interface speed, at 1.2V. It uses single-rank x4 (SRx4) organisation with 8Gb DRAM devices on a 288-pin DIMM. This SKU is the Micron-only variant of UCS-MR-X16G1RT-H, so it is the right match where Micron-sourced modules are specified.
It is intended for the Cisco UCS C220 M5, C240 M5, C480 M5, B200 M5 and B480 M5 servers and HyperFlex HX M5 nodes. The M5 platform provides 6 memory channels per CPU with up to 2 DIMMs per channel. For best performance, populate at least one DIMM per channel per CPU, with multiples of 12 DIMMs ideal.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Registered ECC DDR4 for server-class reliability
- Supports the M5 memory RAS features described in Cisco's M5 memory technical overview
- Cisco-qualified for UCS M5 and HyperFlex HX M5 platforms
- Micron-only sourcing variant of UCS-MR-X16G1RT-H
- Single-rank x4 organisation with 8Gb DRAM devices
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Capacity: 16GB
- Memory type: DDR4 SDRAM Registered DIMM (RDIMM)
- Speed: DDR4-2933 (PC4-23400), up to 2933 MT/s depending on CPU memory interface speed
- Rank/organisation: Single rank x4 (1Rx4)
- DRAM density: 8Gb
- Operating voltage: 1.2V
- Error checking: ECC
- Pins: 288-pin
- Form factor: DIMM
- Sourcing: Micron only
- Platform support: Cisco UCS C220 M5, C240 M5, C480 M5, B200 M5, B480 M5 and HyperFlex HX M5
- Memory channels (M5 platform): 6 per CPU, up to 2 DIMMs per channel
- HyperFlex equivalent PID: HX-MR-X16G1RTHM
FAQs
Q: Which servers does this memory module work with?
A: It is for Cisco UCS C220 M5, C240 M5, C480 M5, B200 M5 and B480 M5 servers, and HyperFlex HX M5 nodes.
Q: What is different about this SKU compared with UCS-MR-X16G1RT-H?
A: This is the Micron-only variant. It has the same 16GB, SRx4 (8Gb), 2933 MT/s specification, but the DRAM is sourced from Micron.
Q: How should the DIMMs be populated for best performance?
A: Populate at least one DIMM per memory channel per CPU. Multiples of 12 DIMMs give the best performance on the M5 platform, which has 6 channels per CPU.
Q: Can I mix it with 3200 MT/s RDIMMs?
A: Do not mix it with the 3200 MT/s RDIMMs (UCS-MR-X16G1RW) except where Cisco's M5 Memory Guide allows it. Check the guide for the population rules.
Q: Will it always run at 2933 MT/s?
A: The module is rated up to 2933 MT/s. The actual speed depends on the memory interface speed of the installed CPU.
