Cisco

Cisco UCS-MP-512GS-B0 | UCS M6 Optane Persistent Memory 512GB, 3200 MHz

SKU:UCS-MP-512GS-B0

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco UCS-MP-512GS-B0 is a 512 GB Intel Optane Persistent Memory module in a DIMM form factor, built for Cisco UCS M6 servers running 3rd Gen Intel Xeon Scalable (Ice Lake) processors. It suits in-memory databases, large-dataset analytics and virtualisation workloads that need more memory capacity per socket than DRAM alone can provide, or storage-class persistent memory through App Direct mode.

The module runs at 3200 MHz and supports both App Direct mode, where data persists and the module behaves like solid-state storage, and Memory Mode, where it acts as large-capacity volatile memory with DRAM as a cache. Up to eight 512 GB modules can be fitted per CPU socket, giving 4 TB of persistent memory per CPU. The 512 GB module sits alongside 128 GB (UCS-MP-128GS-B0) and 256 GB (UCS-MP-256GS-B0) options in the same family. No licence is required, and the operating mode is selected with a separate mode PID: UCS-DCPMM-AD for App Direct or UCS-DCPMM-MM for Memory Mode.

It is supported on Cisco UCS C220 M6, C240 M6 and B200 M6 servers. Two CPUs must be installed when using persistent memory, and all persistent memory modules in a server must be the same capacity. When combined with DRAM, persistent memory goes in slot 2 of each channel and DRAM in slot 1.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Non-volatile operation in App Direct mode, where data persists and the module acts like solid-state storage
- Memory Mode operation as large-capacity volatile memory with DRAM acting as cache
- Higher capacity per slot than DDR4 DRAM for in-memory databases and large datasets
- Up to 4 TB of persistent memory per CPU socket with eight 512 GB modules
- Flexible DRAM to persistent memory configurations including 4+4, 8+4, 8+1 and 8+8
- Supported on Cisco UCS M6 rack and blade servers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID: UCS-MP-512GS-B0
- Description: Intel Optane DC Persistent Memory, 512 GB, 3200 MHz
- Capacity: 512 GB per module
- Clock speed: 3200 MHz (3200 MT/s)
- Form factor: DIMM
- Operating modes: App Direct and Memory Mode
- Supported CPUs: 3rd Gen Intel Xeon Scalable (Ice Lake), except 4309Y, 4310, 4310T and 4316
- Compatible servers: Cisco UCS C220 M6, C240 M6, B200 M6
- Maximum persistent memory per CPU socket: 8 x 512 GB (4 TB)
- Maximum total memory per CPU with 8 x 256 GB DRAM and 8 x 512 GB persistent memory: 6 TB
- Supported DRAM to persistent memory configurations per CPU: 4+4, 8+4, 8+1, 8+8
- Memory Mode DRAM to persistent memory ratios: 1:4, 1:8, 1:16
- CPU requirement: two CPUs installed when using persistent memory
- Slot population: persistent memory in channel slot 2, DRAM in slot 1
- Mixing persistent memory capacities: not supported
- Memory mirroring: DRAM DIMMs only, App Direct mode only
- Spare memory: not supported when persistent memory is installed
- Family capacities: 128 GB, 256 GB, 512 GB

FAQs

Q: Does this module need a licence?
A: No licence is required. The operating mode is selected with a separate mode PID: UCS-DCPMM-AD for App Direct or UCS-DCPMM-MM for Memory Mode.

Q: Which servers and processors does it work with?
A: It is supported on Cisco UCS C220 M6, C240 M6 and B200 M6 servers with 3rd Gen Intel Xeon Scalable (Ice Lake) processors. The 4309Y, 4310, 4310T and 4316 CPUs are not supported.

Q: Can I mix different persistent memory capacities in one server?
A: No. All persistent memory modules in a server must be the same capacity. Mixing 128 GB, 256 GB and 512 GB modules is not supported.

Q: How should it be installed alongside DRAM?
A: Place the persistent memory module in slot 2 of each memory channel, the slot closest to the CPU, and a DRAM DIMM in slot 1. Two CPUs must be installed when using persistent memory.

Q: How does it differ from the other UCS persistent memory SKUs?
A: UCS-MP-512GS-B0 is the 512 GB module. UCS-MP-128GS-B0 is 128 GB and UCS-MP-256GS-B0 is 256 GB, all in the same family.
