Cisco

Cisco UCS-MP-512GS-A0 | UCS M5 Optane Persistent Memory Module, 512GB, 2666 MHz

SKU:UCS-MP-512GS-A0

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The UCS-MP-512GS-A0 is a 512GB Intel Optane Persistent Memory module rated at 2666 MHz, sold by Cisco for UCS M5 servers. It suits large-memory and in-memory database workloads, higher virtualisation density and fast persistent storage on C220 M5, C240 M5 and B200 M5 platforms.

Each module provides 512GB of capacity and can run in Memory Mode, App Direct Mode or Mixed Mode. In Memory Mode the module acts as volatile memory with DRAM as cache, which is the factory default. In App Direct Mode it acts as non-volatile storage, and PMem and DIMM capacity both count toward the CPU capacity limit. The population rules are 2, 4 or 6 PMem modules per CPU alongside a minimum of 6 DIMMs, with two CPUs installed and all PMem modules the same size. PMem goes in channel slot 2, closest to the CPU, with the DIMM in slot 1.

It requires 2nd Generation Intel Xeon Scalable processors and is not supported with 1st Generation processors. No licence or subscription is needed, and the operating mode is selected with the Cisco PIDs UCS-DCPMM-AD or UCS-DCPMM-MM.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Persistent, non-volatile storage-class memory in App Direct Mode
- High-capacity volatile memory expansion in Memory Mode, with DRAM acting as cache
- Mixed Mode splits the module between volatile and persistent capacity
- Memory Mode is the factory default operating mode
- DRAM mirroring supported on the DIMMs in App Direct Mode
- Draws power from the server DIMM slot with no separate power supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Cisco PID: UCS-MP-512GS-A0
- Description: Intel Optane Persistent Memory, 512GB, 2666 MHz
- Capacity: 512GB per module
- Speed: 2666 MHz
- Form factor: Intel Optane Persistent Memory (PMem) DIMM
- Processor requirement: 2nd Generation Intel Xeon Scalable only, 1st Generation not supported
- Operational modes: Memory Mode, App Direct Mode and Mixed Mode
- Mode PIDs: UCS-DCPMM-AD (App Direct Mode), UCS-DCPMM-MM (Memory Mode)
- Minimum population: 2 PMem and 6 DIMMs per CPU
- PMem per CPU: 2, 4 or 6
- Dual-CPU requirement: two CPUs must be installed when PMem is used
- Mixing: all installed PMem must be the same size
- Slot placement: PMem in channel slot 2 (closest to the CPU), DIMM in slot 1
- Memory Mode DIMM to PMem capacity ratio: 1:2 to 1:16 recommended, 1:4 for best performance
- CPU capacity limits (2nd Gen): 1024GB per CPU standard, 2048GB M-class, 4608GB L-class

FAQs

Q: Does the UCS-MP-512GS-A0 need a licence or subscription?
A: No licence or subscription is needed. The operating mode is selected with the Cisco PIDs UCS-DCPMM-AD for App Direct Mode or UCS-DCPMM-MM for Memory Mode.

Q: Which servers and processors does it work with?
A: It is designed for Cisco UCS C220 M5, C240 M5 and B200 M5 servers with 2nd Generation Intel Xeon Scalable (Cascade Lake) processors. It is not supported with 1st Generation Xeon Scalable processors.

Q: How many modules can be installed per CPU?
A: Install 2, 4 or 6 PMem modules per CPU, with a minimum of 6 DIMMs per CPU. Two CPUs must be installed when PMem is used, and all installed PMem must be the same size.

Q: What is the difference between Memory Mode and App Direct Mode?
A: In Memory Mode the module acts as 100% volatile memory with DRAM as cache, and this is the factory default. In App Direct Mode it acts as non-volatile storage.

Q: How does it differ from the other capacities?
A: This 512GB part is the largest capacity in the range. The sibling modules are the 128GB UCS-MP-128GS-A0 and the 256GB UCS-MP-256GS-A0.
