Cisco UCS-ML-X64G4RT-H | UCS M5 64GB DDR4-2933 LRDIMM 4Rx4 Server Memory
SKU:UCS-ML-X64G4RT-H
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 64GB DDR4-2933 load-reduced DIMM is server memory for Cisco UCS M5-generation blade and rack servers built on Intel Xeon Scalable processors. It suits memory expansion and replacement in virtualisation, database and other memory-intensive workloads.
The module is a single 64GB LRDIMM with ECC, organised as 4Rx4 (quad rank, x4) using 8Gb DRAM density and running at 1.2V. It is rated for DDR4-2933, though the effective operating speed follows the highest DDR4 clock supported by the installed CPU, from 2133 to 2933 MHz on 2nd Generation Xeon Scalable processors. The module draws power from the server memory slot, so no separate supply is needed.
On the B200 M5 platform, each CPU provides 6 memory channels with up to 2 DIMMs per channel, giving 24 DIMM slots in total. Some processor SKUs, such as the 6262V, limit memory speed to 2400 MHz.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Load-reduced DIMM design suited to high-capacity memory configurations
- ECC error correction
- 1.2V low-voltage DDR4 operation
- Rated for DDR4-2933 on 2nd Generation Intel Xeon Scalable (Cascade Lake) UCS M5 servers
- Cisco-qualified part for UCS M5 blade and rack servers
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Capacity: 64GB (1 x 64GB)
- Memory type: DDR4 Load-Reduced DIMM (LRDIMM), ECC
- Rated speed: DDR4-2933 MHz
- Ranks per DIMM: 4 (4Rx4)
- DRAM density: 8Gb
- Operating voltage: 1.2V
- Effective speed: runs at the highest DDR4 clock supported by the installed Intel Xeon Scalable CPU (2133 to 2933 MHz on 2nd Gen Xeon Scalable)
- Memory channels (B200 M5): 6 per CPU, up to 2 DIMMs per channel
- DIMM slots (B200 M5): 24 total
- Spare part number: UCS-ML-X64G4RT-H=
FAQs
Q: Which servers does this memory work with?
A: It is designed for Cisco UCS M5 servers, such as the B200 M5 and C-Series M5, with Intel Xeon Scalable processors.
Q: Will it always run at 2933 MHz?
A: Not necessarily. The module runs at the highest DDR4 clock the installed CPU supports. 2nd Generation Xeon Scalable processors support up to 2933 MHz, while some SKUs, such as the 6262V, are limited to 2400 MHz.
Q: Does it need any extra power?
A: No. It operates at 1.2V and is powered directly from the server memory slot.
Q: How does it differ from other 64GB UCS memory options?
A: This SKU is a 64GB LRDIMM using 4Rx4 organisation with 8Gb DRAM density, rated at DDR4-2933. Other 64GB modules may use different rank or module types.
Q: How many modules can a B200 M5 take?
A: The B200 M5 provides 6 memory channels per CPU with up to 2 DIMMs per channel, for 24 DIMM slots in total.
