Cisco UCS-ML-X64G4RS-H | UCS 64GB DDR4-2666 LRDIMM Server Memory, Quad Rank x4
SKU:UCS-ML-X64G4RS-H
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 64GB DDR4-2666 load-reduced DIMM is server memory for Cisco UCS M5-generation servers, including the UCS B200 M5 blade and the C-Series M5 family. It suits virtualisation, database and other memory-intensive workloads where a single module needs to deliver high capacity, and it is aimed at expanding or maintaining an existing UCS installed base.
The module is a quad-rank x4 (4Rx4) LRDIMM rated at DDR4-2666 (PC4-21300) and runs from a 1.2V supply. It uses ECC DDR4 for server-grade reliability. The load-reduced design allows high-capacity memory configurations across the DIMM slots in a UCS server. Memory speed is capped by the memory controller of the installed CPU, so the module will run at the highest speed that processor supports.
The module is powered directly from the server memory slot, so no separate power connection is required. The PID is UCS-ML-X64G4RS-H and it is supplied as a single module.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Load-reduced DIMM design supports high-capacity memory configurations
- ECC DDR4 memory for server reliability
- Quad-rank x4 organisation in a single 64GB module
- Cisco-qualified memory for UCS M5 servers
- Draws power from the server memory slot with no separate supply needed
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCS-ML-X64G4RS-H
- Capacity: 64GB
- Memory type: DDR4 Load-Reduced DIMM (LRDIMM)
- Speed: DDR4-2666 MHz (PC4-21300)
- Ranks per DIMM: 4 (quad rank)
- Data width organisation: x4
- Operating voltage: 1.2V
- Error correction: ECC
- Quantity: Single module
- Platform: Cisco UCS M5-generation servers
FAQs
Q: Which servers is this memory designed for?
A: It is designed for Cisco UCS M5-generation servers, including the UCS B200 M5 blade server and the C-Series M5 family.
Q: Will it always run at 2666 MHz?
A: The module is rated at DDR4-2666 (PC4-21300), but the actual speed is capped by the memory controller of the installed CPU. The server will run it at the highest speed that processor supports.
Q: What type of DIMM is this and how does it differ from an RDIMM?
A: It is a load-reduced DIMM (LRDIMM) in a quad-rank x4 (4Rx4) configuration. The load-reduced design supports higher-capacity memory configurations than standard registered DIMMs.
Q: Does it need any extra power?
A: No. It runs at 1.2V and is powered directly from the server memory slot.
Q: How is it supplied?
A: It is a single 64GB module with the Cisco PID UCS-ML-X64G4RS-H.
