Cisco UCS-HD2T7KL12N | UCS C-Series 2TB 12G SAS 7.2K LFF Hard Drive
SKU:UCS-HD2T7KL12N
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 2 TB hard drive is built for Cisco UCS C-Series rack servers where bulk capacity matters more than raw speed. It is a 3.5-inch large form factor SAS drive spinning at 7,200 RPM, supplied mounted in a drive sled for front-panel drive bays. It is used as the HDD in appliances built on the UCS platform, including the Cisco Expressway CE1200, and suits capacity-focused storage in rack server deployments.
The drive uses a 12 Gb/s SAS interface and standard 512-byte sectors. It is a non-self-encrypting model and is not the 4K-format variant, which matters when matching drives within a RAID volume. The drive is hot-pluggable, so it can be inserted or replaced without powering down the server.
It is listed as an orderable drive in the Cisco UCS C220 M5 LFF spec sheet (UCSC-C220-M5L, up to four 3.5-inch bays) and the UCS C240 M6 LFF spec sheet. It works with the Cisco 12G SAS RAID controller or 12G SAS HBA, and can sit alongside SSDs as long as HDDs and SSDs are kept in separate RAID volumes. The spare part PID is UCS-HD2T7KL12N=.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-pluggable, sled-mounted 3.5-inch drive for front-panel drive bays
- 12 Gb/s SAS interface for Cisco UCS C-Series servers
- Standard 512-byte sector format, not the 4K variant
- Non-self-encrypting 7.2K RPM drive for bulk capacity
- Works with the Cisco 12G SAS RAID controller or 12G SAS HBA
- Can be mixed with SSDs when HDDs and SSDs sit in separate RAID volumes
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCS-HD2T7KL12N
- Description: 2 TB 12G SAS 7.2K RPM LFF HDD
- Drive type: SAS
- Capacity: 2 TB
- Form factor: 3.5-inch large form factor (LFF)
- Spindle speed: 7,200 RPM
- Interface speed: 12 Gb/s SAS
- Sector format: 512-byte, non-self-encrypting
- Hot-pluggable: Yes, mounted in a drive sled
- Spare part PID: UCS-HD2T7KL12N=
FAQs
Q: Which servers is this drive listed for?
A: It is listed as an orderable drive in the Cisco UCS C220 M5 LFF spec sheet (UCSC-C220-M5L, up to four 3.5-inch bays) and the UCS C240 M6 LFF spec sheet. It is also used as the HDD in the Cisco Expressway CE1200 appliance.
Q: What controller does it need?
A: It works with the Cisco 12G SAS RAID controller or the 12G SAS HBA. Embedded software RAID supports SATA HDDs only, so it is not suited to that mode.
Q: Can it be mixed with SSDs in the same server?
A: Yes, on the Cisco 12G SAS RAID controller or HBA, provided HDDs and SSDs are placed in separate RAID volumes.
Q: Is this a 512-byte or 4K sector drive?
A: It is a standard 512-byte sector drive and is not the 4K-format variant. It is also a non-self-encrypting model.
Q: Can I fit or replace it while the server is running?
A: Yes. The drive is hot-pluggable and comes mounted in a sled, so it can be installed in a front-panel bay without powering down the server.
