Cisco

Cisco UCS-CPU-I6314U | Xeon Gold 6314U 32-Core CPU, 2.3GHz, 205W, 1S

SKU:UCS-CPU-I6314U

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Intel Xeon Gold 6314U is a 3rd Gen Intel Xeon Scalable (Ice Lake) processor for single-socket Cisco UCS M6 servers, including the C220 M6, B200 M6 and X210c M6. It also suits HyperFlex M6 nodes. It is aimed at virtualisation, general data centre and high-core-count workloads that need strong compute density from a single CPU.

The processor has 32 cores and 64 threads, a 2.3 GHz base frequency with turbo up to 3.4 GHz, 48 MB of cache and a 205 W TDP. It supports 8 channels of DDR4-3200 memory up to 6 TB, along with Intel Optane Persistent Memory, and provides 64 PCIe 4.0 lanes. It uses the FCLGA4189 socket and is built on a 10 nm process.

This is a single-socket-only part (1S). Cisco allows a maximum of one UCS-CPU-I6314U per server, and it cannot be paired with a second CPU. Memory support covers DDR4 RDIMM and LRDIMM at 3200 MHz.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Intel Speed Select Technology (Base Frequency, Core Power, Turbo Frequency)
- Intel Deep Learning Boost (DL Boost) for AI inference acceleration
- Intel Resource Director Technology (RDT)
- Intel Turbo Boost 2.0 and Hyper-Threading
- Supports Intel Optane Persistent Memory
- ECC memory support
- PCIe Gen 4.0 with 64 lanes

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Processor: Intel Xeon Gold 6314U
- Product collection: 3rd Gen Intel Xeon Scalable (Ice Lake)
- Cores / threads: 32 / 64
- Base frequency: 2.3 GHz
- Max turbo frequency: 3.4 GHz
- Cache: 48 MB
- TDP: 205 W
- Lithography: 10 nm
- Socket: FCLGA4189 (LGA 4189)
- Scalability: 1S only
- Memory type: DDR4-3200
- Memory channels: 8
- Max memory size: 6 TB
- ECC memory: Supported
- Intel Optane Persistent Memory: Supported
- PCI Express: 4.0, up to 64 lanes
- T_CASE: 81 C
- Package size: 77.5 mm x 56.5 mm

FAQs

Q: Can I install two of these CPUs in one server?
A: No. The 6314U is a single-socket-only part. Cisco allows a maximum of one UCS-CPU-I6314U per server, and it cannot be combined with a second CPU.

Q: Which Cisco UCS servers use this processor?
A: It is listed as a CPU option for UCS M6 servers, including the C220 M6 rack server, the B200 M6 blade and the X210c M6 compute node. It is also used in HyperFlex M6 nodes.

Q: What memory does it support?
A: It supports 8 channels of DDR4-3200 memory (RDIMM and LRDIMM) up to 6 TB, plus Intel Optane Persistent Memory.

Q: What is the power requirement of this CPU?
A: The processor has a 205 W TDP. Make sure the server chassis power supplies and cooling are sized for a 205 W CPU.

Q: How does this differ from other Xeon Gold CPUs in the UCS range?
A: The 6314U is a 32-core, 2.3 GHz, 205 W part limited to one socket. Dual-socket Xeon Gold options in the UCS M6 range have different core counts and frequencies and can be paired in a two-CPU server.
