Cisco UCS-CPU-I6230 | Xeon Gold 6230 CPU, 20-Core, 2.1GHz, 125W, 27.5MB
SKU:UCS-CPU-I6230
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco UCS-CPU-I6230 is an Intel Xeon Gold 6230 processor from the 2nd Generation Intel Xeon Scalable family, supplied as a CPU option for Cisco UCS M5 rack servers such as the C240 M5. It is aimed at Big Data and virtualisation workloads where core count and memory bandwidth matter.
This processor has 20 cores running at 2.1GHz with a 125W TDP and 27.5MB of cache. It provides 3 x 10.4 GT/s UPI links, although 2-socket servers use only 2 UPI links. Memory support runs up to DDR4-2933MHz. DIMMs that are faster or slower than the CPU supports are clocked at the lowest common denominator of the CPU and DIMM clock.
In the Cisco UCS C240 M5, a dual-CPU configuration requires two identical CPUs, and two CPUs are needed to support SFF NVMe PCIe SSDs. The 125W class has no ambient-temperature restriction listed in the C240 M5 specifications.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 2nd Generation Intel Xeon Scalable architecture with 20 cores
- 3 x 10.4 GT/s UPI links, with 2 used in 2-socket systems
- Supports DDR4 memory up to 2933MHz
- Suited to Big Data and virtualisation workloads
- Standard CPU option for Cisco UCS M5 rack servers such as the C240 M5
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product ID: UCS-CPU-I6230
- Processor family: 2nd Generation Intel Xeon Scalable, 6000 Series (Xeon Gold 6230)
- Cores: 20
- Clock frequency: 2.1GHz
- Power (TDP): 125W
- Cache size: 27.5MB
- UPI links: 3 x 10.4 GT/s
- Highest DDR4 DIMM clock support: 2933MHz
- Workload type: Big Data, Virtualisation
FAQs
Q: Which Cisco servers is this CPU used in?
A: It is an M5-generation CPU option for Cisco UCS rack servers and is listed among the available CPUs for the UCS C240 M5.
Q: Do I need to fit two of these CPUs?
A: In the C240 M5, a dual-CPU configuration requires two identical CPUs. Two CPUs are also required to support SFF NVMe PCIe SSDs.
Q: What memory speed does this CPU support?
A: It supports DDR4 memory up to 2933MHz. DIMMs that are faster or slower than the CPU supports are clocked at the lowest common denominator of the CPU and DIMM clock.
Q: How many UPI links does it have?
A: The processor supports 3 x 10.4 GT/s UPI links. In 2-socket servers only 2 UPI links are used.
Q: What is the power rating of this CPU?
A: It has a 125W TDP. The 125W class has no ambient-temperature restriction listed in the C240 M5 specifications.
