Cisco UCS-CPU-6148 | Xeon Gold 6148 CPU, 20-Core 2.4 GHz, 150W, 27.5MB

SKU:UCS-CPU-6148

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Intel Xeon Gold 6148 is a 1st Generation Intel Xeon Scalable (Skylake-SP) server processor orderable under the Cisco UCS-CPU-6148 part number. It is built for Cisco UCS M5-generation servers and suits general-purpose and compute-intensive data centre workloads such as virtualisation, NFV and 5G user-plane functions.

This CPU has 20 cores and 40 threads, with a 2.4 GHz base frequency and up to 3.7 GHz Turbo. It carries 27.5 MB of L3 cache and a 150 W TDP, and uses the LGA3647 (Socket P) package on a 14 nm process. Six-channel DDR4-2666 memory is supported, up to 768 GB per CPU, and three UPI links run at 10.4 GT/s for multi-socket configurations.

Cisco lists it for UCS M5 servers including the UCS C220 M5, C240 M5, C480 M5 and B200 M5. Because it is a 150 W part, the server needs a power supply and heat sink sized for a 150 W CPU. Check the relevant server spec sheet to confirm support in a given chassis and CPU-count configuration.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Intel Hyper-Threading Technology for 40 threads from 20 cores
- Intel Turbo Boost Technology 2.0 up to 3.7 GHz
- Intel AVX-512 instruction support for vector-intensive workloads
- Intel AES New Instructions (AES-NI) for hardware-accelerated encryption
- Intel Virtualization Technology and Intel Trusted Execution Technology
- Six-channel DDR4-2666 memory support up to 768 GB per CPU

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Processor family: Intel Xeon Gold (1st Generation Intel Xeon Scalable)
- Processor model: 6148
- Codename: Skylake
- Cores / threads: 20 / 40
- Base frequency: 2.40 GHz
- Max turbo frequency: 3.70 GHz
- L3 cache: 27.5 MB
- Thermal design power (TDP): 150 W
- Socket: LGA3647 (Socket P / FCLGA3647)
- Lithography: 14 nm
- Max memory per CPU: 768 GB
- Memory type: DDR4-2666 (6 channels)
- UPI speed: 10.4 GT/s
- UPI links: 3
- Instruction set extensions: SSE4.2, AVX, AVX2, AVX-512
- Intel Turbo Boost Technology: 2.0
- Intel Hyper-Threading: Yes
- Max thermal specification: 86 C
- Stepping / S-spec: H0 / SR3B6
- Intel ARK ID: 120489

FAQs

Q: Which Cisco UCS servers does the UCS-CPU-6148 work with?
A: Cisco lists it for UCS M5 servers, including the UCS C220 M5, C240 M5, C480 M5 and B200 M5. Check the relevant server spec sheet to confirm support in a given chassis and CPU-count configuration.

Q: What power and cooling does this CPU need?
A: It has a 150 W TDP, so the server needs a power supply and heat sink sized for a 150 W processor. Its maximum thermal specification is 86 C.

Q: What memory does the Xeon Gold 6148 support?
A: It supports six-channel DDR4-2666 memory, up to 768 GB per CPU.

Q: Can it be used in a multi-socket configuration?
A: Yes. It has three UPI links running at 10.4 GT/s for multi-socket operation. The number of CPUs supported depends on the server model, so check the server spec sheet.

Q: Is the HyperFlex part number the same CPU?
A: A HyperFlex variant of the same Xeon Gold 6148 is sold as HX-CPU-6148. This listing is the UCS-CPU-6148 part number for UCS servers.
