Cisco IE-4000-8T4G-E | Industrial Ethernet 4000 8-Port FE Switch, 4x GE Combo, LAN Base

SKU:IE-4000-8T4G-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Industrial Ethernet 4000 Series IE-4000-8T4G-E is a ruggedised, DIN-rail mount Layer 2 switch built for harsh manufacturing, energy and utilities, transportation and smart-city networks. It suits PLC, SCADA and IP camera connectivity, outdoor cabinets, warehouses and ring-resilient topologies.

It provides 8 Fast Ethernet RJ45 copper ports and 4 Gigabit Ethernet combo uplink ports that accept either SFP or RJ45 connections, giving 12 ports in total with 20 Gbps of non-blocking switching capacity. This SKU has no PoE ports and ships with the LAN Base feature set, which can be upgraded to IP Services. It runs from a redundant DC input of 9.6 to 60 VDC, draws 35 W and operates from -40 to +75 C under datasheet conditions.

The combo uplinks work with Cisco SFPs including industrial-temperature parts such as GLC-FE-100FX-RGD=, GLC-SX-MM-RGD=, GLC-LX-SM-RGD=, GLC-ZX-SM-RGD= and GLC-T-RGD=. It can be managed through the Device Manager GUI, Industrial Network Director or Cisco Catalyst Center.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Ruggedised, compact DIN-rail form factor hardened for vibration, shock, surge and noise immunity
- Redundancy protocols including REP, PRP, MRP ring, HSR, EtherChannel and Flex Links
- Redundant DC power input with dying gasp
- Industrial protocols including EtherNet/IP (CIP), PROFINET v2, Modbus TCP and IEEE 1588 PTP v2
- Layer 2 switching with 1:1 static NAT and IPv4 static routing
- Security features including 802.1x, SSH, SNMPv3, TACACS+/RADIUS, DHCP snooping, Dynamic ARP Inspection and IP Source Guard
- Zero-touch SwapDrive replacement using the removable SD card
- Utility support including Power Profile 2011/2017, GOOSE messaging and IEC 61850-3 / IEEE 1613 compliance

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Product number: IE-4000-8T4G-E
- Total ports: 12
- RJ45 copper ports: 8 x Fast Ethernet (10/100)
- GE combo (SFP or RJ45) uplinks: 4
- Dedicated SFP fibre ports: None
- PoE/PoE+ ports: None
- Software feature set: LAN Base (upgradable to IP Services)
- Switching capacity: 20 Gbps non-blocking
- Forwarding rate: Line rate for all ports and all packet sizes
- DRAM: 1 GB
- Onboard flash memory: 128 MB
- Removable SD flash card: 1 GB
- Console: Mini-USB and RJ-45
- Alarm I/O: 2 alarm inputs, 1 alarm output relay
- Unicast MAC addresses: 16,000
- Number of VLANs: 1,000
- IGMP multicast groups: 1,000
- Egress queues: 4
- Input voltage: Redundant DC input, nominal 9.6 to 60 VDC
- Maximum input current: 3.7 A
- Power consumption: 35 W (no PoE load)
- Dimensions (H x W x D): 155.4 x 155.4 x 129.2 mm
- Weight: 2.88 kg
- Operating temperature: -40 to +75 C (enclosure dependent)
- Storage temperature: -40 to +85 C
- Humidity: 5% to 95% non-condensing
- Ingress protection: IP30
- MTBF: 591,070 hours

FAQs

Q: Which feature set does this switch run, and can it be upgraded?
A: It ships with the LAN Base feature set. It can be upgraded to IP Services using the L-IE4000-RTU= licence.

Q: Does it support PoE?
A: No. This SKU has no PoE or PoE+ ports, so powered devices need their own power source.

Q: How is the switch powered?
A: It uses a redundant DC input of 9.6 to 60 VDC with a maximum input current of 3.7 A. Compatible Cisco industrial DIN-rail supplies include PWR-IE50W-AC=, PWR-IE65W-PC-DC= and PWR-IE170W-PC-DC=.

Q: Which SFPs work in the combo uplink ports?
A: The four combo ports accept a wide range of Cisco SFPs, including industrial-temperature GLC-FE-100FX-RGD=, GLC-SX-MM-RGD=, GLC-LX-SM-RGD=, GLC-ZX-SM-RGD= and GLC-T-RGD=, as well as BX and CWDM/DWDM SFPs. Non-industrial SFPs require operating-temperature derating.

Q: How can this switch be managed?
A: It can be managed through the web-based Device Manager GUI with Express Setup, Cisco Catalyst Center or Industrial Network Director.
