Cisco

Cisco IE-4000-8GT8GP4G-E | IE4000 16-Port Gigabit PoE+ Industrial Switch, LAN Base

SKU:IE-4000-8GT8GP4G-E

$4,258.00 USD
Sale Sold out
Shipping calculated at checkout.

1 in stock

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco Industrial Ethernet 4000 Series IE-4000-8GT8GP4G-E is a ruggedised, DIN-rail mount managed Gigabit switch built for harsh industrial environments. It suits manufacturing, energy and utility substations, transportation and ITS, smart cities, warehouses and roadways, where it connects PLCs and SCADA systems and powers PoE devices such as IP cameras, wireless access points, IP phones and badge readers.

The port layout is 8 x Gigabit RJ45 copper ports and 8 x Gigabit PoE/PoE+ (802.3at) ports sharing a 240W PoE budget, plus 4 x Gigabit combo uplinks that take either SFP or RJ45 (one of each combo pair is active at a time). Switching capacity is 20 Gbps nonblocking with line-rate forwarding. It runs Cisco IOS with the LAN Base feature set, which can be upgraded to IP Services using L-IE4000-RTU=. Power is a redundant DC input, nominal 9.6 to 60 VDC, and the switch operates from -40C to +75C.

The combo uplinks accept SFPs including industrial-rated modules such as GLC-SX-MM-RGD=, GLC-LX-SM-RGD=, GLC-ZX-SM-RGD= and GLC-T-RGD=. Management is through the web-based Device Manager, Cisco Catalyst Center, Industrial Network Director or Prime Infrastructure.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Ruggedised, DIN-rail compliant design for harsh industrial environments
- Resilient ring topologies with REP, PRP, MRP, HSR, EtherChannel and Flex Links
- Industrial automation protocols: EtherNet/IP (CIP), PROFINET and Modbus TCP
- IEEE 1588v2 PTP precision time protocol
- SwapDrive zero-config replacement for fast recovery after a failure
- Web-based Device Manager and Express Setup for quick deployment
- Layer 2 switching with 1:1 static NAT and IPv4 static routing in LAN Base
- Security features including 802.1x, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, SSH, SNMPv3, TACACS+ and RADIUS

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Total ports: 20
- RJ45 copper ports: 8 x 10/100/1000
- PoE/PoE+ ports: 8 x 10/100/1000 (802.3at)
- PoE power budget: 240W maximum
- Uplinks: 4 x Gigabit Ethernet combo (SFP or RJ45), one of each pair active at a time
- Software licence: LAN Base (upgradable to IP Services)
- Switching capacity: 20 Gbps nonblocking
- Forwarding rate: line rate for all ports and packet sizes
- Memory: 1 GB DRAM
- Flash: 128 MB onboard plus 1 GB removable SD card
- Console: Mini-USB and RJ-45
- Alarm I/O: 2 alarm inputs, 1 alarm output relay
- Egress queues: 4
- Unicast MAC addresses: 16,000
- VLANs: 1,000
- IGMP multicast groups: 1,000
- Input voltage: redundant DC, nominal 9.6 to 60 VDC
- Maximum input current: 4.3 A
- Power consumption: 40 W excluding PoE (measured at 9.6 V)
- Dimensions (H x W x D): 155.4 x 155.4 x 129.2 mm
- Weight: 2.88 kg
- Operating temperature: -40C to +75C
- Storage temperature: -40C to +85C
- Humidity: 5% to 95% non-condensing
- Ingress protection: IP30
- MTBF: 519,190 hours

FAQs

Q: Which licence does this switch run and can it be upgraded?
A: It runs the LAN Base feature set. It can be upgraded to IP Services using L-IE4000-RTU=, which adds IP multicast, dynamic routing protocols, IPv6 routing, MACsec, TrustSec and VRF-lite.

Q: How is the switch powered?
A: It uses a redundant DC input, nominal 9.6 to 60 VDC, with 40 W consumption excluding PoE. The 240W PoE budget must also be covered by the DIN-rail power supply. PoE-capable options include PWR-IE170W-PC-AC=, PWR-IE240W-PCAC-L= and PWR-IE480W-PCAC-L=. The 50W units do not support PoE.

Q: What can I fit in the uplink ports?
A: The 4 combo uplinks take SFPs or RJ45. Industrial-rated modules include GLC-SX-MM-RGD=, GLC-LX-SM-RGD=, GLC-ZX-SM-RGD= and GLC-T-RGD=. CWDM, DWDM and 100BASE-FX/LX SFPs are also supported, though support varies by software version.

Q: Can all four combo uplinks be used as both SFP and RJ45 at once?
A: No. Each combo port has an SFP and an RJ45 interface, and only one of the pair is active at a time. Across the four uplinks you have 4 active Gigabit connections.

Q: How do I manage it?
A: Through the built-in web Device Manager, Cisco Catalyst Center, Industrial Network Director or Prime Infrastructure.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
