Cisco

Cisco IE-4000-8GT4G-E | IE 4000 8-Port Gigabit Industrial Switch, 4x SFP/RJ45, LAN Base

SKU:IE-4000-8GT4G-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco Industrial Ethernet 4000 Series IE-4000-8GT4G-E is a ruggedised, DIN-rail Layer 2 Gigabit Ethernet switch built for harsh industrial environments such as manufacturing floors, substations, rail and roadside cabinets, smart city sites and warehouses. It is fanless, rated IP30 and operates from -40 to +75 C.

This SKU provides 8 x 10/100/1000 RJ45 copper access ports and 4 x Gigabit combo uplinks, where each uplink can run as SFP or RJ45 with one active per port. It is a non-PoE model, so connected devices need their own power. It ships with the LAN Base feature set, with IPv4 static routing and 1:1 static NAT at Layer 3, and can be upgraded to IP Services. Forwarding is line rate on all ports and packet sizes, with 1 GB DRAM, 128 MB onboard flash and a 1 GB removable SD card.

Power is a redundant DC input, nominal 9.6 to 60 VDC, drawing up to 3.7 A with 35 W consumption. Cisco IE power supplies such as PWR-IE50W-AC=, PWR-IE65W-PC-AC=/DC= and PWR-IE170W-PC-AC=/DC= are ordered separately. The combo uplinks accept Cisco industrial SFPs including GLC-SX-MM-RGD=, GLC-LX-SM-RGD= and GLC-ZX-SM-RGD=, and the switch can be managed with Cisco Industrial Network Director or Cisco Catalyst Center.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hardened for vibration, shock, surge and noise immunity across a -40 to +70 C range
- Compact DIN-rail compliant form factor with fanless operation
- Resiliency options including REP, PRP, MRP, HSR, EtherChannel, Flex Links and redundant power input
- SwapDrive zero-touch replacement of a failed switch
- Hardware-assisted NAT and IEEE 1588 PTP
- Industrial protocol support including EtherNet/IP (CIP), PROFINET and Modbus TCP
- Security including 802.1x, SSH, SNMPv3, TACACS+, RADIUS, DHCP snooping, Dynamic ARP Inspection and IP Source Guard
- Web-based Device Manager and Express Setup, with management via Cisco Industrial Network Director or Catalyst Center

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Total ports: 12
- RJ45 access ports: 8 x 10/100/1000
- Uplinks: 4 x Gigabit combo (SFP or RJ45, one active per port)
- PoE: none (non-PoE model)
- Default software licence: LAN Base (upgradable to IP Services)
- Memory: 1 GB DRAM, 128 MB onboard flash, 1 GB removable SD card
- Forwarding rate: line rate for all ports and all packet sizes
- Egress queues: 4
- Unicast MAC addresses: 16,000
- VLANs: 1,000
- IGMP multicast groups: 1,000
- Alarms: two alarm inputs (dry contact), one alarm output relay
- Input voltage: redundant DC, nominal 9.6 to 60 VDC
- Maximum input current: 3.7 A
- Power consumption: 35 W (measured at 9.6 V)
- Dimensions (H x W x D): 155.4 x 155.4 x 129.2 mm
- Weight: 2.88 kg
- Operating temperature: -40 to +75 C
- Storage temperature: -40 to +85 C
- Relative humidity: 5% to 95% non-condensing
- Ingress protection: IP30
- MTBF: 591,240 hours
- Mounting: DIN-rail, fanless

FAQs

Q: Which licence does this switch run?
A: It runs the LAN Base feature set, which is Layer 2 with IPv4 static routing and 1:1 static NAT. It can be upgraded to IP Services if you need the extended feature set.

Q: Does it support PoE?
A: No. This is a non-PoE model, so any connected devices that need power must be powered separately.

Q: How is the switch powered?
A: It uses a redundant DC input, nominal 9.6 to 60 VDC, at up to 3.7 A. Cisco IE power supplies such as PWR-IE50W-AC=, PWR-IE65W-PC-AC=/DC= and PWR-IE170W-PC-AC=/DC= are ordered separately.

Q: Which SFPs work in the combo uplinks?
A: The combo uplinks accept Cisco industrial SFPs including GLC-SX-MM-RGD=, GLC-LX-SM-RGD=, GLC-ZX-SM-RGD=, GLC-BX40-U-I=/D-I= and GLC-FE-100FX-RGD=. Each combo port runs as either SFP or RJ45, with one active at a time.

Q: How does this differ from other IE 4000 models?
A: This SKU has 8 Gigabit copper access ports and 4 Gigabit combo uplinks with no PoE, running LAN Base. Other IE 4000 variants differ in port count, PoE support or licence tier.
