• Cisco CP-8845-K9 black desk phone with red accents, 5-inch color display
1 1

Cisco

Cisco CP-8845-K9 | IP Phone 8845 5-Line HD Video, Charcoal, CUCM

CP-8845-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco IP Phone 8845 is a business-class desktop video phone from the Cisco IP Phone 8800 Series, built for knowledge workers and executives in enterprise Cisco Unified Communications Manager, Business Edition 6000 and Hosted Collaboration Solution deployments. This CP-8845-K9 is the Charcoal model running CUCM firmware, not the multiplatform (3PCC) version.

It has a 5-inch widescreen VGA (800 x 480) backlit colour display, 720p HD two-way video using H.264/AVC, and wideband audio on the handset, speakerphone and headset. Five programmable line keys support multiple calls per line. A built-in 2-port 10/100/1000 Ethernet switch lets a PC share the phone's network connection, and power comes from IEEE 802.3af/802.3at PoE (Class 2). Bluetooth 4.1 LE/EDR Class 1 supports wireless headsets, and Cisco Intelligent Proximity links the phone with a mobile device.

The phone needs an Enhanced User Connect License (UCL) to register with Cisco Unified Communications Manager. It works with CUCM 8.5.1 (non-secured mode only), 8.6.2, 9.1.2, 10.5.2 and 11.0 or later. Accessories include the CP-8800-VIDEO-WMK wall-mount kit, CP-8800-B/S-VID-BEZEL bezels, CP-8800-FS foot stand and CP-PWR-CUBE-4 power cube.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- One-touch 720p HD desktop video
- Wideband audio with echo cancellation, noise reduction and automatic gain control
- Five programmable line keys with multicall-per-line
- Cisco Intelligent Proximity for audio path moving, call-history sync and contact sync with a mobile device
- Built-in Gigabit Ethernet switch for PC connection
- Encrypted voice and video with SRTP and TLS
- Built-in VPN client and Cisco Expressway remote access
- Bluetooth headset support and electronic hookswitch via the AUX port
- Hearing Aid Compatible handset and ADA-compliant dial pad
- Replaceable bezel and optional wall-mount kit

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Programmable line keys: 5
- Display: 5-inch WVGA (800 x 480), 24-bit colour, backlit
- Video: 720p HD two-way (encode and decode), H.264/AVC
- Audio codecs: G.711 a-law and mu-law, G.722, G.729a/b, iLBC, iSAC, G.722.1, OPUS
- Ethernet switch: internal 2-port 10/100/1000BASE-T, RJ-45, single LAN connection for phone and PC
- VLAN support: 802.1Q, separate VLANs for PC and phone
- Bluetooth: 4.1 LE, EDR Class 1, up to 20 m, HFP and PBAP profiles
- Headset ports: RJ-9 analogue wideband headset jack, AUX port for electronic hookswitch
- Power over Ethernet: IEEE 802.3af/802.3at, Class 2, CDP and LLDP-PoE
- Optional power supply: Cisco IP Phone Power Cube 4 (48V) with country power cord
- Network protocols: SIP, SDP, IPv4/IPv6, DHCP, DNS, TFTP, HTTPS, CDP, LLDP-MED, RTP/RTCP
- Security: secure boot, MIC/LSC certificates, 802.1x (EAP-FAST, EAP-TLS), TLS signalling, SRTP media encryption, SSH server, SSL VPN client
- Dimensions (H x W x D): 228.78 x 257.34 x 98.39 mm, excluding foot stand
- Weight with handset: 1.35 kg
- Casing: polycarbonate/ABS textured plastic
- Operating temperature: 0 to 40 C
- Operating humidity: 10 to 90% non-condensing
- Foot stand: two-position, 35 and 50 degree viewing angles
- Physical security: Kensington Security Slot
- Colour: Charcoal

FAQs

Q: Does the 8845 need a licence to work?
A: Yes. It needs an Enhanced User Connect License (UCL) to connect to Cisco Unified Communications Manager. The licence is purchased separately from the phone.

Q: How is the phone powered?
A: It runs on IEEE 802.3af or 802.3at PoE (Class 2). For non-PoE deployments, the optional Cisco IP Phone Power Cube 4 (CP-PWR-CUBE-4) with a country-specific cord can be used.

Q: Which call control platforms does it work with?
A: CP-8845-K9 runs CUCM firmware and works with Cisco Unified Communications Manager 8.5.1 (non-secured mode only), 8.6.2, 9.1.2, 10.5.2 and 11.0 or later, as well as Cisco Business Edition 6000 and Hosted Collaboration Solution.

Q: Is this the multiplatform (3PCC) version?
A: No. CP-8845-K9 is the Charcoal model with CUCM firmware. The multiplatform version is a separate part number.

Q: Can I connect a PC through the phone?
A: Yes. The built-in 2-port 10/100/1000 Ethernet switch lets a PC share the phone's network connection, with separate VLANs supported for the phone and PC.

Q: Which accessories are available for the 8800 series video phones?
A: Compatible accessories include the CP-8800-VIDEO-WMK wall-mount kit, CP-8800-B-VID-BEZEL and CP-8800-S-VID-BEZEL bezels, the CP-8800-FS foot stand, the CP-DX-HS spare handset and the CP-PWR-CUBE-4 power cube.
