• Cisco 8851 IP phone with white design, 5-line grayscale LCD, PoE
1 1

Cisco

Cisco CP-8811-W-K9 | IP Phone 8811, 5-Line, Gigabit PoE, White

CP-8811-W-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco IP Phone 8811 is a business-class IP desk phone from the Cisco IP Phone 8800 Series. It suits small to large enterprises running on-premises Cisco call control, Hosted Collaboration Solution or third-party hosted call control. This SKU is the white colour variant.

The phone has five programmable line keys, a 5-inch 800 x 480 backlit grayscale display and wideband audio with G.722, G.722.2 and Opus support alongside G.711, G.729ab, iLBC and iSAC. A built-in 2-port 10/100/1000 Ethernet switch lets a PC share the phone's LAN connection, with separate 802.1Q VLANs for phone and PC. It is powered by IEEE PoE Class 2 (802.3af, also compatible with 802.3at switches). Handset and headset connect through RJ-9 ports, and an AUX port supports electronic hookswitch control.

It works with Cisco Unified Communications Manager 12.5 and later, Unified CME 10.0 and later, Business Edition 6000 and Hosted Collaboration Solution, and needs an Enhanced User Connect Licence to register to Unified Communications Manager. Optional accessories include the CP-8800-WMK wall-mount kit, the CP-8800-FS spare foot stand and the CP-PWR-CUBE-4 power cube for non-PoE deployments.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Five programmable line keys that can be set to multiple directory numbers or features such as speed dial, with multicall-per-line support
- Wideband audio for high-fidelity voice, with a hearing-aid-compatible handset and full-duplex speakerphone
- Built-in Gigabit Ethernet switch lets a PC share the phone's LAN connection
- Encrypted voice with TLS signalling and SRTP media, plus secure boot and device authentication
- 802.1x supplicant with EAP-FAST and EAP-TLS, plus HTTPS and SSH server support
- Backlit acoustic keys for audio path selection between handset, headset and speakerphone
- Supports Cisco EnergyWise and is Energy Star qualified
- Localised language support, including right-to-left on-screen text

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Line keys: 5 programmable
- Display: 5-inch, 800 x 480, backlit grayscale
- Colour: White
- Ethernet switch: internal 2-port 10/100/1000BASE-T, RJ-45
- VLAN: IEEE 802.1Q separate VLANs for PC and phone
- Power over Ethernet: IEEE PoE Class 2, compatible with 802.3af and 802.3at
- Power input rating: 0.917 A, 48 V DC
- Audio codecs: G.711 (A-law and u-law), G.722, G.722.2, G.729ab, iLBC, iSAC, Opus
- Handset port: wideband-capable handset, RJ-9
- Headset port: analog wideband-capable RJ-9
- Electronic hookswitch: via third-party headset on AUX port
- Signalling and media security: TLS and SRTP
- Dimensions (H x W x D): 229.1 x 257.34 x 40 mm, excluding foot stand
- Weight (with handset): 1.17 kg
- Operating temperature: 0 to 40 C
- Operating humidity: 10 to 90%, non-condensing
- Foot stand: two-position, 35 and 50 degree viewing angles
- Physical security: Kensington Security Slot compatible

FAQs

Q: Does this phone need a licence?
A: Yes. It requires an Enhanced User Connect Licence (UCL) to connect to Cisco Unified Communications Manager.

Q: How is the phone powered?
A: It is powered by PoE Class 2 (IEEE 802.3af, also compatible with 802.3at switches). For non-PoE deployments, the optional Cisco IP Phone Power Cube 4 (CP-PWR-CUBE-4) with the matching country power cord, such as CP-PWR-CORD-AU for Australia, can be used.

Q: Which call control platforms does it work with?
A: Cisco Unified Communications Manager 12.5 and later, Unified CME 10.0 and later, Business Edition 6000 and Hosted Collaboration Solution.

Q: Can I connect a PC through the phone?
A: Yes. The built-in 2-port 10/100/1000 Ethernet switch lets a PC share the phone's LAN connection, with separate 802.1Q VLANs for phone and PC traffic.

Q: How does this differ from CP-8811-K9=?
A: CP-8811-K9= is the Charcoal version of the 8811. This SKU is the white variant.

Q: Which accessories does it work with?
A: Compatible accessories include the CP-8800-WMK wall-mount kit, CP-8800-FS spare foot stand, CP-8800-B-BEZEL and CP-8800-S-BEZEL bezels, CP-DX-W-HS white spare handset and CP-DX-W-CORD white handset cord.
