Cisco CP-860-MCHR-BN | Wireless Phone 860 Multi-Charger, 4 Phones + 4 Batteries

CP-860-MCHR-BN

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco 860 Multi-Charger Bundle is a desktop charging station for the Cisco Wireless Phone 860 and 860S. It is built for shared charging points in healthcare, retail and warehouse environments, where staff hand over phones between shifts and swap in charged spare batteries to keep handsets in service.

The bundle combines the 860 Multicharger Base with four Desktop Dual Charger Modules and a power supply. Each module has a phone cup and a battery cup, so four phones and four spare batteries can charge at the same time across eight slots. Charging time is 3.5 hours for an 860 phone with battery or for a standalone 860 battery on wall power. Two LEDs per module show the status of each slot: solid red while charging, solid green when charged, and off for an empty slot or a fault. The base accepts up to four modules in any configuration, so it can be rearranged by swapping modules.

This bundle is for the Cisco Wireless Phone 860 and 860S and the 860 spare battery only. It is not interchangeable with the Cisco Wireless Phone 840 multichargers. The sibling bundle CP-860-BAT-MCHR-BN charges eight batteries instead of four phones and four batteries.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Charges 4 phones and 4 spare batteries at the same time from one wall outlet
- Modular base takes up to 4 charger modules, so it can be reconfigured, for example 2 phones and 6 batteries, or 8 batteries
- Complete bundle with base, charger modules and power supply, so no separate power supply is needed
- Per-slot LED status indicators show charging, charged and empty or fault states
- Charger plastics withstand cleaning with mild detergent, isopropyl alcohol or diluted bleach (10% or less)
- Suited to shared charging stations where staff swap in charged batteries during a shift

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: CP-860-MCHR-BN
- Charger capacity: four phones and four batteries (eight slots)
- Included base: CP-860-MCHR= Multicharger Base with power supply
- Included modules: 4 x Desktop Dual Charger Modules (phone and battery cups)
- Base capacity: up to four desktop charger modules in any configuration
- Base power supply model: FSP090-ABAN3
- Charging indicators: two LEDs per module, one per slot
- LED status: solid red = charging, solid green = charged, off = empty slot or error
- Charging time, 860 phone with battery (wall power): 3.5 hours
- Charging time, 860 standalone battery (wall power): 3.5 hours
- Compatibility: Cisco Wireless Phone 860 and 860S, and 860 spare battery (CP-860-BAT=)

FAQs

Q: Does this charger need a separate power supply?
A: No. The multicharger base is powered by its own power supply with wall power cord (model FSP090-ABAN3). Use only the power supply supplied with the multicharger base.

Q: Which phones and batteries does it charge?
A: It charges the Cisco Wireless Phone 860 and 860S and the 860 spare battery (CP-860-BAT=). It is not compatible with the Cisco Wireless Phone 840 multichargers.

Q: How is CP-860-MCHR-BN different from CP-860-BAT-MCHR-BN?
A: CP-860-MCHR-BN charges four phones and four batteries using four Desktop Dual Charger Modules. CP-860-BAT-MCHR-BN is the battery-only version that charges eight batteries.

Q: Can the charger layout be changed later?
A: Yes. The base accepts up to four desktop charger modules in any configuration. Swapping modules lets you move to, for example, 2 phones and 6 batteries, or 8 batteries.

Q: How long does a full charge take?
A: On wall power, an 860 phone with battery and a standalone 860 battery each take 3.5 hours to charge.

Q: What do the LEDs on each module mean?
A: Each slot has its own LED. Solid red means charging, solid green means charged, and the LED is off when the slot is empty or there is an error.
