Aruba JH328A | OfficeConnect 1420 5-Port Gigabit PoE+ Switch, 32W

JH328A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The OfficeConnect 1420 5G PoE+ is an unmanaged Layer 2 Gigabit desktop switch for small offices and open-plan desks that need simple plug-and-play connectivity. It powers IP phones, wireless access points and security cameras over PoE+ without any configuration or software management.

It has five 10/100/1000 RJ-45 autosensing ports with Auto-MDIX. Ports 1-4 supply PoE/PoE+ (IEEE 802.3at) from a total 32W budget, with up to 30W per port, and also support 802.3af devices. Switching capacity is 10 Gbps with up to 7.4 Mpps throughput, a 2048-entry MAC address table and jumbo frame support up to 9,216 bytes. There are no SFP uplink ports on this model.

The switch is fanless for silent operation and uses an internal power supply rated 100-240 VAC, 50/60 Hz, with a maximum power rating of 40W. As an unmanaged switch it needs no software licence or subscription. This 5-port PoE+ model sits between the JH327A 5-port non-PoE switch and the JH330A 8-port PoE+ switch with a 64W budget.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Unmanaged plug-and-play operation with no configuration
- Auto-speed negotiation and Auto-MDIX on all RJ-45 ports
- IEEE 802.3at PoE+ with up to 30W per port, also supports 802.3af devices
- Energy Efficient Ethernet (IEEE 802.3az) with auto power-down on idle ports
- IEEE 802.3x flow control
- QoS with IEEE 802.1p prioritisation and DSCP support
- Per-port LED display
- Fanless silent design with internal power supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 5 x 10/100/1000 RJ-45 autosensing
- PoE: PoE/PoE+ (IEEE 802.3at) on ports 1-4
- PoE budget: 32W total
- Uplinks: no SFP/SFP+ ports
- Management: unmanaged Layer 2
- Switching capacity: 10 Gbps
- Throughput: up to 7.4 Mpps
- MAC address table: 2048 entries
- Packet buffer: 1 Mb
- Latency: under 3 us at 100 Mb, under 2.6 us at 1000 Mb
- Jumbo frames: up to 9,216 bytes
- Power supply: internal, 100-240 VAC, 50/60 Hz
- Maximum power rating: 40W
- Acoustic: fanless
- Mounting: desktop
- Dimensions (W x D x H): 15.77 x 10.49 x 2.69 cm
- Weight: 0.5 kg
- Operating temperature: 0 to 40 C
- Operating humidity: 15% to 95% noncondensing
- Storage temperature: -40 to 70 C
- Safety: UL 60950, IEC 60950-1, EN 60950-1
- Emissions: FCC Part 15 Subpart B Class A

FAQs

Q: Does this switch need a licence or subscription?
A: No. It is an unmanaged switch and requires no software licence or subscription.

Q: How much PoE power does it provide?
A: Ports 1-4 support PoE/PoE+ (IEEE 802.3at) from a shared 32W total budget, up to 30W per port. The fifth port does not supply PoE.

Q: Does it have SFP uplink ports?
A: No. All five ports are 10/100/1000 RJ-45. For SFP uplinks, look at other models in the OfficeConnect 1420 series.

Q: How does it differ from the JH327A and JH330A?
A: The JH327A is a 5-port Gigabit model without PoE. The JH330A is an 8-port PoE+ model with a 64W budget. The JH328A is the 5-port model with PoE+ on 4 ports and a 32W budget.

Q: Can it be managed remotely?
A: No. It is an unmanaged Layer 2 switch with no web interface or CLI, so it works straight out of the box.
