Vendor:Arista
Arista QSFP-40G-LRL4 | 40G QSFP+ | LRL4 | 1310 nm CWDM | 1 km SMF | LC duplex
QSFP-40G-LRL4
Vendor:AristaArista QSFP-40G-LRL4 | 40G QSFP+ | LRL4 | 1310 nm CWDM | 1 km SMF | LC duplex
Cost-effective 40G LRL4 QSFP+ transceiver delivering up to 1 km reach on single-mode fiber via LC duplex. Uses 1310 nm CWDM lanes to provide reliable campus and metro edge connectivity with simpler cabling than parallel solutions. -
Vendor:Arista
Arista QSFP-40G-PLR4 | 40G QSFP+ | PLR4 | 1310 nm parallel | 10 km SMF | MPO-12
QSFP-40G-PLR4
Vendor:AristaArista QSFP-40G-PLR4 | 40G QSFP+ | PLR4 | 1310 nm parallel | 10 km SMF | MPO-12
40G PLR4 QSFP+ parallel single-mode transceiver delivering up to 10 km reach over MPO-12 cabling. Supports native 40G links and 4x10G LR channelization for long-distance breakout deployments. -
Vendor:Arista
Arista QSFP-40G-PLRL4 | 40G QSFP+ | 40GBASE-PLRL4 (PSM4) | 1310nm | 1km SMF | MPO/MTP-12 | 4x10G breakout
QSFP-40G-PLRL4
Vendor:AristaArista QSFP-40G-PLRL4 | 40G QSFP+ | 40GBASE-PLRL4 (PSM4) | 1310nm | 1km SMF | MPO/MTP-12 | 4x10G breakout
Parallel single‑mode 40G QSFP+ transceiver for up to 1 km over OS2 SMF using an MPO/MTP‑12 interface. Supports 4x10G breakout to LC via an MPO‑to‑4xLC harness when the switch/port supports breakout mode. Ideal for spine/leaf or aggregation links that require longer reach on single‑mode without duplex LR4. -
Vendor:Arista
Arista QSFP-40G-SRBD | 40G QSFP+ | 40GBASE-BIDI | 850/910nm | 100m OM3 / 150m OM4 | LC duplex
QSFP-40G-SRBD
Vendor:AristaArista QSFP-40G-SRBD | 40G QSFP+ | 40GBASE-BIDI | 850/910nm | 100m OM3 / 150m OM4 | LC duplex
40GBASE-BiDi QSFP+ transceiver enabling 40G over existing duplex MMF with standard LC connectors. Delivers up to 100 m on OM3 or 150 m on OM4 by using two wavelengths over a single duplex pair—ideal for cost-effective 10G-to-40G upgrades without MPO cabling. -
Vendor:Arista
Arista QSFP-40G-SRBD-R | 40G QSFP+ | 40GBASE-BiDi Rx-only | BiDi dual‑wavelength MMF | 100m OM3 / 150m OM4 | LC duplex
QSFP-40G-SRBD-R
Vendor:AristaArista QSFP-40G-SRBD-R | 40G QSFP+ | 40GBASE-BiDi Rx-only | BiDi dual‑wavelength MMF | 100m OM3 / 150m OM4 | LC duplex
40G BiDi receiver-only QSFP+ for duplex multimode fiber runs using LC cabling. Ideal for monitoring or unidirectional applications where only receive capability is required. Supports up to 100 m on OM3 or 150 m on OM4 with simplified LC duplex connectivity versus MPO-based SR4. -
Vendor:Arista
Arista QSFP-40G-UNIV | 40G QSFP+ | Universal duplex | 1310 nm | 150m MMF / 500m SMF | LC duplex
QSFP-40G-UNIV
Vendor:AristaArista QSFP-40G-UNIV | 40G QSFP+ | Universal duplex | 1310 nm | 150m MMF / 500m SMF | LC duplex
Universal 40G QSFP+ transceiver that operates over both multimode and single-mode duplex fiber using an LC connector. Enables easy migration by supporting up to 150 m on OM3/OM4 MMF and up to 500 m on SMF without changing patch panels or optics. -
Vendor:Arista
Arista QSFP-40G-XSR4 | 40G QSFP+ | 40GBASE-XSR4 | 850nm | 300m OM3 / 400m OM4 | MPO-12
QSFP-40G-XSR4
Vendor:AristaArista QSFP-40G-XSR4 | 40G QSFP+ | 40GBASE-XSR4 | 850nm | 300m OM3 / 400m OM4 | MPO-12
High-density 40GBASE-XSR4 QSFP+ transceiver for extended short-reach multimode links. Delivers up to 300 m on OM3 or 400 m on OM4 with MPO-12 connectivity, ideal for spine–leaf, aggregation, or campus core uplinks where extra reach over MMF is required. Supports 4x10G breakout with appropriate cabling. -
Vendor:Arista
Arista SFP-10G-DZ-T | 10G SFP+ | 10GBASE-DWDM | Tunable C‑band 50 GHz ITU | 1528–1565 nm | 80 km SMF | LC duplex
SFP-10G-DZ-T
Vendor:AristaArista SFP-10G-DZ-T | 10G SFP+ | 10GBASE-DWDM | Tunable C‑band 50 GHz ITU | 1528–1565 nm | 80 km SMF | LC duplex
Tunable 10G DWDM SFP+ covering the full C‑band on the 50 GHz ITU grid for flexible wavelength provisioning. Designed for long‑haul metro links up to 80 km over single‑mode fiber with LC duplex interface and DOM support. -
Vendor:Arista
Arista SFP-10G-ERBD-D | 10G SFP+ | 10GBASE-ER BiDi | Tx1330/Rx1270 nm | 40km SMF | LC simplex
SFP-10G-ERBD-D
Vendor:AristaArista SFP-10G-ERBD-D | 10G SFP+ | 10GBASE-ER BiDi | Tx1330/Rx1270 nm | 40km SMF | LC simplex
10Gbps SFP+ 10GBASE-ER BiDi transceiver for single-fiber SMF links up to 40km. The Downlink variant transmits at 1330nm and receives at 1270nm via an LC simplex interface; deploy with the matching 40km Uplink module at the far end. Supports DDM/DOM and hot-swap for simplified operations. -
Vendor:Arista
Arista SFP-10G-ERBD-U | 10G SFP+ | 10GBASE-ER BiDi | Tx1270/Rx1330 nm | 40km SMF | LC simplex
SFP-10G-ERBD-U
Vendor:AristaArista SFP-10G-ERBD-U | 10G SFP+ | 10GBASE-ER BiDi | Tx1270/Rx1330 nm | 40km SMF | LC simplex
10Gbps SFP+ 10GBASE-ER BiDi transceiver for single-fiber SMF links up to 40km. The Uplink variant transmits at 1270nm and receives at 1330nm via an LC simplex interface; deploy with the matching 40km Downlink module at the far end. Supports DDM/DOM and hot-swap for simplified operations. -
Vendor:Arista
Arista SFP-10G-ERLBD-D | 10G SFP+ | 10GBASE-ER BiDi | Tx1330/Rx1270 nm | 30km SMF | LC simplex
SFP-10G-ERLBD-D
Vendor:AristaArista SFP-10G-ERLBD-D | 10G SFP+ | 10GBASE-ER BiDi | Tx1330/Rx1270 nm | 30km SMF | LC simplex
10Gbps SFP+ 10GBASE-ER BiDi transceiver for single-fiber SMF links up to 30km. The Downlink variant transmits at 1330nm and receives at 1270nm via an LC simplex interface; deploy with the matching Uplink module at the far end. Supports DDM/DOM and hot-swap for simplified operations. -
Vendor:Arista
Arista SFP-10G-ERLBD-U | 10G SFP+ | 10GBASE-ER BiDi | Tx1270/Rx1330 nm | 30km SMF | LC simplex
SFP-10G-ERLBD-U
Vendor:AristaArista SFP-10G-ERLBD-U | 10G SFP+ | 10GBASE-ER BiDi | Tx1270/Rx1330 nm | 30km SMF | LC simplex
10Gbps SFP+ 10GBASE-ER BiDi transceiver for single-fiber SMF links up to 30km. The Uplink variant transmits at 1270nm and receives at 1330nm via an LC simplex interface; deploy with the matching Downlink module at the far end. Supports DDM/DOM and hot-swap for simplified operations. -
Vendor:Arista
Arista SFP-10G-LRL | 10GbE SFP+ | 10GBASE-LRL | 1310nm | 1km SMF | LC duplex | DDM
SFP-10G-LRL
Vendor:AristaArista SFP-10G-LRL | 10GbE SFP+ | 10GBASE-LRL | 1310nm | 1km SMF | LC duplex | DDM
Energy-efficient SFP+ transceiver for medium-reach 10GbE links over single-mode fiber. The LRL variant extends reach to 1 km at 1310 nm using LC duplex connectors—ideal for campus, metro access, and distribution layers where full LR (10 km) is unnecessary. -
Vendor:Arista
Arista SFP-10G-SRL | 10GbE SFP+ | 10GBASE-SRL | 850nm | 100m OM3 / 150m OM4 | LC duplex | DDM
SFP-10G-SRL
Vendor:AristaArista SFP-10G-SRL | 10GbE SFP+ | 10GBASE-SRL | 850nm | 100m OM3 / 150m OM4 | LC duplex | DDM
Compact SFP+ optical transceiver for 10GbE short-reach links using multimode fiber. The SRL variant provides efficient power usage and reliable performance over 100 m on OM3 or 150 m on OM4 with duplex LC connectivity—ideal for access, aggregation, and server uplinks. -
Vendor:Arista
Arista SFP-1G-LX | 1G SFP | 1000BASE‑LX | 1310 nm | 10 km SMF | LC duplex
Standards‑based 1000BASE‑LX SFP for reliable 1 GbE fiber uplinks. Operates at 1310 nm over single‑mode fiber up to 10 km with LC duplex interface and DOM support. -
Vendor:Arista
Arista SFP-1G-T | 1G SFP | 100/1000BASE‑T | RJ45 copper | 100 m Cat5e/6
Copper RJ45 SFP module enabling 100/1000 Mb/s Ethernet over Cat5e/6 cabling up to 100 m. Ideal for legacy copper drops and mixed media environments.
