• Moxa Compatible SFP-1GSXLC-BCC 1GB Multi-Mode Fiber Transceiver
1 1

Blue Cable Co

SFP-1GSXLC-BCC | Moxa Compatible 1GB Multi-Mode 550m (1000BASE-SX)

SFP-1GSXLC-BCC

33 in stock

$49.50 inc. GST
$45.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SFP-1GSXLC-BCC is a drop-in compatible replacement for the Moxa SFP-1GSXLC. It delivers plug-and-play operation in Moxa industrial Ethernet switches and other compatible equipment requiring Gigabit multi-mode fibre connectivity. - IEEE 802.3z 1000BASE-SX compliance guarantees interoperability with any standards-based Gigabit Ethernet switch port - SFP form factor transceiver operating at 1.25 Gbps over multi-mode fibre at 850nm wavelength via LC duplex connector - Supports up to 550m reach on OM2, OM3, and OM4 fibre (300m on 62.5um OM1 fibre) - Digital Diagnostic Monitoring (DDM) function provides real-time access to temperature, voltage, transmit power, and receive power parameters - Commercial temperature rating of 0 to 60 degrees C suitable for industrial control and automation environments - Hot-swappable design with differential LVPECL inputs and outputs for reliable signal integrity

Features

• IEEE 802.3z compliance ensures the transceiver will initialize and link with any vendor's standards-compliant Gigabit Ethernet SFP port, including multi-vendor network environments
• 850nm VCSEL technology optimized for multi-mode fibre transmission, using 8B/10B line encoding to deliver 1 Gbps data throughput at a 1.25 Gbps line rate
• Reach scales with fibre grade: 300m on legacy 62.5um OM1, 550m on OM2/OM3/OM4, and up to 1km on laser-optimized OM3/OM4/OM5 under optimal link budget conditions
• DDM capability exposes optical power budget in real time, enabling proactive fault isolation by monitoring transmit power, receive power, temperature, voltage, and bias current without external test equipment
• Differential LVPECL I/O architecture with TTL signal detect indicator provides robust electrical interface and loss-of-signal detection for rapid link failure response
• Hot-swappable SFP footprint with Class 1 laser classification (EN 60825-1 compliant) allows field replacement without system power-down in industrial control systems and enterprise switch infrastructure
• Maximum 1W power draw supports high-density SFP switch deployments without exceeding typical per-port power budgets in managed and unmanaged Gigabit platforms

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-1GSXLC-BCC
Compatible Replacement For: SFP-1GSXLC
Compatibility: Moxa compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP
Data Rate: 1.25 Gbps
Standard: IEEE 802.3z 1000BASE-SX
Wavelength: 850nm
Fibre Type: Multi-Mode (MMF)
Connector Type: LC duplex
Max Reach: Up to 550m on OM2/OM3/OM4 fibre, 300m on 62.5um OM1 fibre (per datasheet, subject to fibre and link conditions)
DOM Support: Yes (Digital Diagnostic Monitoring)
Operating Temperature: 0 to 60 degrees C
Power Consumption: Max 1W

FAQs

Q: Will this work in place of the Moxa SFP-1GSXLC?
A: Yes. The SFP-1GSXLC-BCC is a direct replacement for the Moxa SFP-1GSXLC, built to the same IEEE 802.3z 1000BASE-SX specification with matching SFP form factor, 1.25 Gbps data rate, 850nm wavelength, and LC duplex connector. It offers plug-and-play compatibility with Moxa switches and any equipment that accepts the original module.

Q: Which Moxa switches and equipment are compatible with this transceiver?
A: This transceiver is compatible with Moxa industrial Ethernet switches in the SFP-1G module accessory family. It will operate in any Moxa switch or device with a Gigabit Ethernet SFP port designed to accept 1000BASE-SX optics at 850nm over multi-mode fibre. If your equipment lists SFP-1GSXLC as a supported module, this transceiver will function identically.

Q: What fibre types are required to achieve the specified 550m reach?
A: To achieve 550m transmission, you must use 50um multi-mode fibre rated OM2 (500 MHz·km) or higher grade such as OM3 or OM4. Legacy 62.5um OM1 fibre limits reach to approximately 275-300m. For distances approaching the upper limit, verify your link budget accounts for connector insertion loss, splice loss, and fibre attenuation to maintain adequate receive power margin.

Q: Can I read the optical power levels from this transceiver while the link is active?
A: Yes. This transceiver supports Digital Diagnostic Monitoring (DDM), also called Digital Optical Monitoring (DOM), which exposes real-time transmit power, receive power, temperature, supply voltage, and laser bias current via the I2C interface. Most managed switches and network operating systems can query these parameters to monitor link health, detect degraded fibre, or troubleshoot intermittent connectivity without physical intervention.

Q: Does this transceiver support auto-negotiation or do I need to force the port speed?
A: The transceiver complies with IEEE 802.3z auto-negotiation for 1000BASE-X. In most cases, both ends will auto-negotiate to 1000 Mbps full-duplex without manual configuration. However, if deploying in a 10G SFP+ port running at reduced speed, you may need to manually configure the host port to 1000 Mbps, as many 10G interfaces do not auto-detect 1G optics by default.
