• Arista Compatible SFP-1G-LX-BCC 1GB LX Transceiver Module
1 1

Blue Cable Co

SFP-1G-LX-BCC | Arista Compatible 1GB Single-Mode 10km (1000BASE-LX)

SFP-1G-LX-BCC

28 in stock

$56.10 AUD
$56.10 AUD
$56.10 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The SFP-1G-LX-BCC is a drop-in compatible replacement for the Arista SFP-1G-LX. This hot-pluggable transceiver delivers 1000BASE-LX connectivity over single-mode fibre with duplex LC connectors. - Compliant with IEEE 802.3z 1000BASE-LX and SFP MSA standards, ensuring interoperability with Arista switches and routers with SFP ports - 1.25Gbps data rate over single-mode fibre at 1310nm wavelength, up to 10km transmission distance on 9/125um SMF - Digital diagnostic monitoring support per SFF-8472, providing real-time access to transmit power, receive power, temperature, voltage, and bias current parameters - Duplex LC connector interface with single 3.3V power supply and power consumption under 1W - Hot-swappable SFP form factor with commercial temperature range 0 to 70 degrees C

Features

• IEEE 802.3z 1000BASE-LX compliance guarantees electrical and optical interoperability with vendor equipment implementing the same Gigabit Ethernet standard over single-mode fibre
• 1310nm FP laser transmitter with PIN photodetector receiver architecture, providing sufficient link budget for 10km transmission over OS1 or OS2 single-mode fibre
• SFF-8472 digital diagnostic monitoring interface exposes real-time optical power levels, temperature, bias current, and supply voltage via I2C, enabling proactive link health assessment without traffic interruption
• Hot-swappable design allows module insertion and removal without powering down the host platform, supporting in-service upgrades and replacements
• Single 3.3V supply with <1W power consumption reduces thermal load per port, suitable for high-density switch environments
• Duplex LC connector interface compatible with standard OS1 and OS2 single-mode patch cords, widely deployed in metro and campus fibre infrastructures

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-1G-LX-BCC
Compatible Replacement For: SFP-1G-LX
Compatibility: Arista compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP
Data Rate: 1.25Gbps
Wavelength: 1310nm
Fibre Type: Single-Mode (9/125um SMF)
Connector Type: Duplex LC
DOM Support: Yes (SFF-8472 compliant)
Standards: IEEE 802.3z 1000BASE-LX, SFP MSA
Max Reach: Up to 10km (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0 to 70 degrees C (commercial)
Power Supply: Single 3.3V
Power Consumption: <1W

FAQs

Q: Will this work in place of the Arista SFP-1G-LX?
A: Yes. This transceiver is electrically and optically compatible with the Arista SFP-1G-LX. It conforms to the same IEEE 802.3z 1000BASE-LX standard, operates at 1.25Gbps with 1310nm wavelength over single-mode fibre, and uses the standard SFP form factor. It is plug-and-play compatible with Arista switches and routers that accept the original module.

Q: Which Arista platforms support this transceiver?
A: This module is compatible with any Arista switch or router with an SFP port that supports 1000BASE-LX transceivers, including data centre switches, campus switches, and platforms requiring Gigabit Ethernet over single-mode fibre. Consult your platform documentation to confirm the SFP slot supports 1G operation at 1310nm wavelength.

Q: What fibre type and maximum reach does this module support?
A: This transceiver operates over OS1 or OS2 single-mode fibre (9/125um) with duplex LC connectors. It supports link lengths up to 10km at 1310nm wavelength. Actual reach depends on fibre attenuation, splice loss, connector quality, and link budget. For links approaching 10km, verify the combined path loss does not exceed the module's optical power budget.

Q: How do I access the digital diagnostic monitoring data?
A: The module implements SFF-8472 DDM with I2C address A2h. Your switch or NOS can read real-time values for transmit optical power, receive optical power, laser bias current, supply voltage, and module temperature. These parameters allow you to detect weak signals, monitor link degradation, and verify optical power levels without external test equipment.

Q: Can I use this module with multi-mode fibre or at wavelengths other than 1310nm?
A: No. This is a 1310nm single-mode transceiver designed for OS1/OS2 9/125um fibre. It will not function correctly with OM3, OM4, or other multi-mode fibres due to modal dispersion and core size mismatch. The receiver and transmitter are optimised for 1310nm operation only and cannot be used with 850nm, 1550nm, or BiDi wavelength schemes.
