• Moxa Compatible SFP-10GSRLC-T-BCC 10GBASE-SR Transceiver Module
1 1

Blue Cable Co

SFP-10GSRLC-T-BCC | Moxa Compatible 10GB Multi-Mode 300m (10GBASE-SR)

SFP-10GSRLC-T-BCC

35 in stock

$62.70 inc. GST
$57.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SFP-10GSRLC-T-BCC is a drop-in compatible replacement for the Moxa SFP-10GSRLC-T. This plug-and-play SFP+ module delivers reliable 10 Gigabit Ethernet connectivity in Moxa industrial switches and networking platforms equipped with SFP+ ports. - IEEE 802.3ae 10GBASE-SR compliance guarantees interoperability with standard 10GbE networks over multimode fibre - SFP+ form factor with 850nm VCSEL technology, supporting 33m over OM1, 82m over OM2, 300m over OM3, and 400m over OM4 multimode fibre via duplex LC connector - Digital optical monitoring (DOM) provides real-time visibility into optical power, temperature, laser bias current, and supply voltage for proactive link management - Extended industrial temperature range of -40 to 85 degrees C for deployment in harsh environments including factory automation and outdoor installations - Hot-swappable SFP+ design with low power consumption for high-density industrial Ethernet applications - SFF-8431 and SFF-8432 SFP+ MSA compliant with full duplex operation at 10.3125 Gbps line rate

Features

• IEEE 802.3ae 10GBASE-SR and SFP+ MSA compliance ensure reliable multimode 10G Ethernet operation with full-duplex transmission at 10.3125 Gbps line rate, guaranteeing protocol-level interoperability across mixed-vendor industrial networks
• 850nm VCSEL laser architecture optimized for multimode fibre transmission with reach scaling by fibre grade: 33m over OM1, 82m over OM2, 300m over OM3, and 400m over OM4, subject to link budget and installation quality
• Digital optical monitoring (DOM) exposes real-time transceiver telemetry including transmit and receive optical power levels, module temperature, laser bias current, and supply voltage via I2C interface per SFF-8472 specification
• Industrial-grade thermal design rated for -40 to 85 degrees C ambient operation, enabling deployment in factory automation, outdoor enclosures, transportation systems, and other harsh environments where commercial-grade optics cannot operate
• Hot-pluggable SFP+ interface with low power consumption (typically under 1W) supports live module insertion and removal without network interruption, simplifying maintenance and enabling high port-density switch configurations
• VCSEL technology delivers lower power consumption and reduced thermal output compared to edge-emitting laser designs, improving system reliability and enabling denser rack configurations in space-constrained industrial installations
• Duplex LC connector interface provides separate transmit and receive paths for full-duplex operation with high port density and field-proven mechanical reliability in vibration-prone industrial settings

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we'll deliver a replacement part before you return the faulty item, minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-10GSRLC-T-BCC
Compatible Replacement For: SFP-10GSRLC-T
Compatibility: Moxa compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10 Gbps (10.3125 Gbps line rate)
Wavelength: 850nm
Fibre Type: Multi-mode (MMF)
Connector Type: Duplex LC
DOM Support: Yes (Digital Optical Monitoring)
Standards: IEEE 802.3ae 10GBASE-SR, SFF-8431, SFF-8432 SFP+ MSA
Max Reach: 33m (OM1), 82m (OM2), 300m (OM3), 400m (OM4)
Operating Temperature: -40 to 85 degrees C (-40 to 185 degrees F)

FAQs

Q: Will this work in place of the Moxa SFP-10GSRLC-T?
A: Yes. The SFP-10GSRLC-T-BCC is electrically and mechanically identical to the Moxa SFP-10GSRLC-T. It conforms to the same IEEE 802.3ae 10GBASE-SR standard, uses the same SFP+ form factor, operates at the same 850nm wavelength, and supports the same multimode fibre types and reach distances. This module is plug-and-play compatible with Moxa switches and networking equipment with SFP+ ports expecting a 10GBASE-SR transceiver.

Q: Which Moxa platforms does this module support?
A: This module works in any Moxa switch, router, or networking device with an SFP+ port that supports 10GBASE-SR transceivers. The extended temperature variant is designed for use with Moxa industrial Ethernet platforms that require -40 to 85 degrees C operation. Compatibility depends on the host device supporting SFP+ MSA-compliant modules with 10 Gbps Ethernet capability over multimode fibre at 850nm wavelength.

Q: What multimode fibre grade is required to reach 300m?
A: To achieve 300m transmission distance, you must use OM3 multimode fibre with 2000 MHzkm modal bandwidth. OM4 fibre extends reach to 400m. Lower-grade OM2 fibre limits reach to 82m, and legacy OM1 fibre supports only 33m. Actual achievable distance also depends on connector loss, splice loss, and total link optical budget. The duplex LC interface requires separate transmit and receive fibres.

Q: How do I access DOM monitoring data from this transceiver?
A: DOM parameters are accessed via the I2C interface defined in SFF-8472 using address A2h. Most network operating systems expose these values through CLI commands or SNMP MIBs. You can monitor real-time optical transmit power, optical receive power, module temperature, laser bias current, and supply voltage. DOM thresholds and alarm flags are also available. Your Moxa platform documentation describes the specific commands or interface for reading SFP+ diagnostic data.

Q: Can this module operate outside the -40 to 85 degrees C range during brief temperature excursions?
A: No. The -40 to 85 degrees C specification is the continuous operating temperature range. Operating the module outside this range may cause link errors, reduced optical power, or transceiver shutdown. For temporary non-operating conditions, the module can withstand storage temperatures from -40 to 85 degrees C. If your application experiences temperature excursions beyond the operating spec, the module should be powered down or the environment controlled to remain within the rated range.
