• Arista Compatible SFP-10G-LR 10GBASE-LR Transceiver Module
1 1

Blue Cable Co

SFP-10G-LR-Arista-BCC | Arista Compatible 10GB Single-Mode 10km (10GBASE-LR)

SFP-10G-LR-ARISTA-BCC

43 in stock

$90.20 inc. GST
$82.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SFP-10G-LR-Arista-BCC is a drop-in compatible replacement for the Arista SFP-10G-LR-ARISTA. This plug-and-play SFP+ transceiver integrates seamlessly with Arista network platforms supporting 10GBASE-LR ports. - IEEE 802.3ae 10GBASE-LR compliance guarantees interoperability across standards-compliant 10 Gigabit Ethernet platforms - SFP+ form factor with 10.3125 Gbps data rate over duplex single-mode fibre, 1310nm wavelength, LC connector, up to 10km reach - Digital Optical Monitoring (DOM) support via SFF-8472 interface provides real-time telemetry of optical power, temperature, voltage, and bias current - Compliant with SFF-8431 and SFF-8432 mechanical and electrical specifications for reliable hot-pluggable operation - Commercial temperature range (0 to 70 degrees Celsius) for standard networking environments - Tested for compatibility with Arista switching and routing platforms requiring 10GBASE-LR connectivity

Features

• IEEE 802.3ae compliance defines optical specifications including transmitter output power, receiver sensitivity, and link budget requirements, ensuring predictable performance and interoperability across multi-vendor 10 Gigabit Ethernet infrastructures
• SFF-8431 electrical interface specification governs high-speed serial signalling between host and transceiver, defining signal integrity requirements for 10 Gb/s operation and ensuring consistent compatibility across switches, routers, and network interface cards
• 1310nm DFB laser technology provides optimal chromatic dispersion and attenuation characteristics for single-mode fibre transmission, balancing cost and performance for metro, campus, and enterprise backbone deployments
• SFF-8472 Digital Diagnostic Monitoring exposes real-time operating parameters including optical transmit and receive power, module temperature, supply voltage, and laser bias current, enabling proactive link troubleshooting and performance validation
• Hot-pluggable SFP+ design allows field installation and replacement without powering down the host platform, minimising network disruption during maintenance or capacity expansion
• LC duplex connector interface with single-mode fibre supports typical optical power budgets of 8 to 11 dB, enabling reliable 10km links over standard G.652 SMF with appropriate fibre quality and cleanliness

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-10G-LR-ARISTA-BCC
Compatible Replacement For: SFP-10G-LR-ARISTA
Compatibility: Arista compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10.3125 Gbps
Wavelength: 1310nm
Fibre Type: Single-Mode Fiber (SMF)
Connector Type: LC duplex
DOM Support: Yes (SFF-8472)
Standards: IEEE 802.3ae 10GBASE-LR, SFF-8431, SFF-8432
Max Reach: Up to 10km (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0 to 70 degrees Celsius (commercial)

FAQs

Q: Will this work in place of the Arista SFP-10G-LR-ARISTA?
A: Yes. This module is designed as a plug-and-play drop-in replacement for the Arista SFP-10G-LR-ARISTA. It conforms to the same IEEE 802.3ae 10GBASE-LR standard, uses the same SFP+ form factor, operates at 10.3125 Gbps over single-mode fibre at 1310nm, and supports the same 10km reach specification. The module will initialise and operate identically in Arista platforms requiring 10GBASE-LR connectivity.

Q: Which Arista platforms support this transceiver?
A: This transceiver is compatible with Arista switches and routers featuring SFP+ ports that support 10GBASE-LR optics. The module adheres to SFF-8431 electrical and SFF-8432 mechanical specifications, ensuring compatibility with standards-compliant SFP+ slots. For platform-specific validation or questions about a particular Arista model, contact Blue Cable Co with your switch or router model number.

Q: What single-mode fibre type is required for 10km transmission?
A: This transceiver requires OS1 or OS2 compliant single-mode fibre (G.652 standard). The 1310nm wavelength and typical optical power budget of 8 to 11 dB support up to 10km transmission over duplex SMF with LC connectors. Actual reach depends on fibre quality, splice loss, connector insertion loss, and total link attenuation. Use clean, low-loss fibre and connectors to achieve rated distance.

Q: How do I access DOM data to monitor link health?
A: Digital Optical Monitoring is accessible via the SFF-8472 two-wire serial interface. Most Arista network operating systems expose DOM parameters through CLI commands or management interfaces, displaying real-time transmit power, receive power, module temperature, supply voltage, and laser bias current. These telemetry values assist with link troubleshooting, verifying optical budgets, and identifying degraded fibre or connector issues before complete link failure.

Q: Can this module be used in a mixed-vendor 10GBASE-LR link?
A: Yes. Because this transceiver conforms to IEEE 802.3ae 10GBASE-LR, it is designed to interoperate with other standards-compliant 10GBASE-LR modules regardless of vendor. The standard defines wavelength, optical power levels, and receiver sensitivity to ensure compatibility. Verify that both link ends meet 10GBASE-LR specifications, use clean single-mode fibre, and confirm total link loss is within the optical power budget for reliable cross-vendor operation.
