• Cisco Compatible SFP-10G-BX40U-I 10GBASE-BX40U Transceiver Module
1 1

Blue Cable Co

SFP-10G-BX40U-I-BCC | Cisco Compatible 10G Single-Mode 40km (10GBASE-BX40U)

SFP-10G-BX40U-I-BCC

Stock Status: Enquire

$146.30 inc. GST
$133.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The SFP-10G-BX40U-I-BCC is a drop-in compatible replacement for the Cisco SFP-10G-BX40U-I. This SFP+ transceiver provides plug-and-play compatibility with Cisco switches and routers requiring 10GBASE-BX40-U upstream connectivity. - 10GBASE-BX40-U standard compliance guarantees interoperability with any IEEE-compliant downstream BiDi transceiver on the same link - SFP+ form factor, 10 Gbps data rate, 1270nm transmit and 1330nm receive wavelengths over single-mode fibre to 40km - Bidirectional operation over a single strand of SMF using simplex LC connector, reducing fibre infrastructure by 50% - Digital Optical Monitoring (DOM) per SFF-8472 MSA enables real-time monitoring of optical power, temperature, bias current, and supply voltage - Hot-swappable installation in any SFP+ port with no host downtime required - Compliant with SFP+ MSA specifications (SFF-8431, SFF-8432, SFF-8472) for universal platform compatibility

Features

• 10GBASE-BX40-U upstream standard ensures link compatibility only with 10GBASE-BX40-D downstream transceivers transmitting 1330nm and receiving 1270nm, never with another upstream unit
• Single-fibre bidirectional architecture separates transmit and receive by wavelength rather than by strand, halving fibre pair requirements in point-to-point links
• SFF-8472 DOM interface exposes optical transmit power, receive power, temperature, laser bias current, and supply voltage over I2C for threshold-based alarming and trending
• Compliant with SFP+ MSA mechanical (SFF-8432) and electrical (SFF-8431) specifications for host interoperability across switches, routers, and NICs with SFP+ cages
• Hot-pluggable design supports insertion and removal without powering down the host system, enabling maintenance without service interruption
• 16 dB minimum optical power budget engineered for 40km reach over OS2 single-mode fibre under typical deployment conditions
• Industrial temperature variants rated for -40°C to 85°C operation in outdoor cabinets, remote sites, and harsh environments where commercial-grade optics fail

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: SFP-10G-BX40U-I-BCC
Compatible Replacement For: SFP-10G-BX40U-I
Compatibility: Cisco compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10 Gbps
Standards: 10GBASE-BX40-U, IEEE 802.3ae, SFF-8431, SFF-8432, SFF-8472
Wavelength: 1270nm TX / 1330nm RX
Fibre Type: Single-Mode (SMF)
Connector Type: Simplex LC
Max Reach: Up to 40km (per datasheet, subject to fibre and link conditions)
DOM Support: Yes (SFF-8472)
Operating Temperature: 0°C to 70°C (commercial), -40°C to 85°C (industrial variants available)
Power Consumption: Maximum 1.0W

FAQs

Q: Will this work in place of the Cisco SFP-10G-BX40U-I?
A: Yes. The SFP-10G-BX40U-I-BCC is designed as a plug-and-play replacement for the Cisco SFP-10G-BX40U-I. It matches the same 10GBASE-BX40-U standard, SFP+ form factor, 1270nm TX / 1330nm RX wavelength pair, 10 Gbps data rate, and 40km reach specification. Insert it into any SFP+ port where the Cisco reference SKU is specified.

Q: Which Cisco platforms support this transceiver?
A: This transceiver works in any Cisco switch, router, or appliance with an SFP+ port that supports 10GBASE-BX operation. Compatibility is determined by the host port supporting the 10GBASE-BX standard and SFP+ form factor, not by a specific model list. Consult your platform documentation to confirm 10GBASE-BX support on the intended port.

Q: Why must I pair this upstream unit with a downstream transceiver?
A: BiDi transceivers achieve bidirectional communication over a single fibre strand by using complementary wavelength pairs. The SFP-10G-BX40U-I upstream unit transmits at 1270nm and receives at 1330nm. It must connect to a downstream unit (such as SFP-10G-BX40D-I) that transmits 1330nm and receives 1270nm. Connecting two upstream or two downstream units will not establish a link because their wavelengths do not align.

Q: What fibre type and quality are required for 40km reach?
A: This transceiver requires OS2 single-mode fibre (G.652 standard) with clean simplex LC terminations. Actual reach depends on fibre attenuation, splice loss, connector insertion loss, and patch panel count. The module provides a 16 dB optical power budget. If your link budget exceeds this due to long distance or high loss, measure end-to-end attenuation and verify it stays within the transceiver transmit power and receiver sensitivity window.

Q: Can I monitor link health and optical parameters in real time?
A: Yes. This transceiver supports Digital Optical Monitoring (DOM) per SFF-8472. Your switch or NOS can query real-time transmit power, receive power, module temperature, laser bias current, and supply voltage over the I2C management interface. Use these parameters to detect degrading fibre, failing lasers, or thermal issues before they cause link failure. DOM thresholds are factory-programmed and accessible via standard commands.
