• Palo Alto Compatible 25GBASE-LR SFP28 Transceiver Module
1 1

Blue Cable Co

PAN-SFP28-25GBASE-LR-BCC | Palo Alto Compatible 25GB Single-Mode 10km (25GBASE-LR)

PAN-SFP28-25GBASE-LR-BCC

3 in stock

$320.10 inc. GST
$291.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The PAN-SFP28-25GBASE-LR-BCC is a drop-in compatible replacement for the Palo Alto PAN-SFP28-25GBASE-LR. This SFP28 transceiver provides plug-and-play compatibility with Palo Alto Networks firewalls featuring 25G SFP28 interfaces. - IEEE 802.3cc 25GBASE-LR compliance guarantees interoperability with standards-based 25 Gigabit Ethernet infrastructure - SFP28 form factor operating at 25 Gbps over single-mode fibre with LC duplex connector, 1310nm wavelength, and 10km maximum reach on OS2 fibre - Digital Diagnostic Monitoring (DOM) support enables real-time visibility into optical power levels, temperature, bias current, and supply voltage for proactive link health management - Hot-swappable design allows installation and removal without interrupting host equipment operation - Compliant with SFP28 MSA (SFF-8402), SFF-8431, and SFF-8432 specifications ensuring mechanical and electrical compatibility with standard SFP28 host ports - Commercial temperature range (0 to 70°C) suited for data centre and enterprise firewall deployments

Features

• IEEE 802.3cc 25GBASE-LR compliance ensures interoperability across multi-vendor 25G Ethernet environments and future-proofs deployments using standardized optical specifications
• Dual-rate capability supporting both 10G and 25G Ethernet applications on the same physical infrastructure, allowing network operators to upgrade link speeds without replacing fibre cabling
• 1310nm wavelength operation with DFB (Directly Modulated Laser) transmitter delivers 8 dB minimum link budget, providing margin for patch panel insertion loss, connector degradation, and fibre attenuation over the full 10km span
• Real-time DOM parameters accessible via I2C interface per SFF-8472 specification enable proactive monitoring of Tx/Rx optical power, temperature, and bias current for predictive maintenance and rapid troubleshooting
• Hot-swappable form factor with detection circuitry allows module insertion and removal during live operation without requiring host port shutdown or system reboot
• Low power consumption design (1.2W typical) reduces thermal load in high-density firewall deployments and supports passive cooling in space-constrained rack environments
• Multi-rate operation from 8.5 to 28.1 Gbps supports 10G Ethernet (10.31 Gbps) and 25G Ethernet (25.78 Gbps) protocols on a single optical platform

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: PAN-SFP28-25GBASE-LR-BCC
Compatible Replacement For: PAN-SFP28-25GBASE-LR
Compatibility: Palo Alto compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP28
Data Rate: 25 Gbps (25GBASE-LR)
Wavelength: 1310nm
Fibre Type: Single-Mode (SMF)
Connector Type: LC Duplex
DOM Support: Yes (Digital Diagnostic Monitoring)
Standards: IEEE 802.3cc (25GBASE-LR), SFP28 MSA (SFF-8402), SFF-8431, SFF-8432
Max Reach: Up to 10km on OS2 single-mode fibre (per datasheet, subject to fibre quality and link conditions)
Operating Temperature: 0°C to 70°C (commercial temperature range)
Max Power Consumption: 1.2W typical

FAQs

Q: Will this work in place of the Palo Alto PAN-SFP28-25GBASE-LR?
A: Yes. The PAN-SFP28-25GBASE-LR-BCC is engineered to the same IEEE 802.3cc 25GBASE-LR standard, uses the identical SFP28 form factor, operates at 25 Gbps over single-mode fibre at 1310nm with 10km reach, and provides plug-and-play compatibility with Palo Alto Networks firewall platforms featuring 25G SFP28 ports. The module is pre-programmed for seamless recognition by Palo Alto hardware.

Q: Which Palo Alto firewall models support this transceiver?
A: This transceiver is compatible with Palo Alto Networks firewall platforms equipped with 25G SFP28 interfaces. Palo Alto designs its interfaces to industry standards (IEEE 802.3 and SFF specifications), so any firewall with a 25G SFP28 port will support 25GBASE-LR modules. Verify your specific firewall model features SFP28 ports by consulting the front panel description in the Palo Alto hardware reference guide for your platform series.

Q: What is the minimum fibre quality required to achieve the full 10km reach at 25G?
A: The module is specified for 10km reach on OS2 (G.652) single-mode fibre, which is standard for long-reach applications. It provides an 8 dB link budget at 25 Gbps. To achieve full 10km reach, ensure your fibre plant has low insertion loss (typically under 0.5 dB/km for OS2 at 1310nm), clean and properly terminated LC connectors, and minimal splice or patch panel loss. Degraded fibre, dirty connectors, or excessive patch points will reduce usable distance.

Q: Does this module require FEC to operate at 25G over 10km?
A: Some 25GBASE-LR implementations require RS-FEC (Reed-Solomon Forward Error Correction) on the host ports for full-reach operation at 25G. This is a host equipment characteristic, not a module limitation. Check whether your Palo Alto firewall platform mandates FEC for 25G links at 10km. The module itself supports multi-rate operation from 8.5 to 28.1 Gbps and will operate at lower speeds or shorter distances without FEC if your firewall permits it.

Q: Can I monitor the optical link health in real time using this transceiver?
A: Yes. The module features full DOM (Digital Diagnostic Monitoring) per SFF-8472, exposing real-time parameters including transmit optical power (Tx), receive optical power (Rx), module temperature, laser bias current, and supply voltage. On Palo Alto firewalls, you can retrieve these values via CLI commands such as 'show transceiver-detail' for the relevant interface. Monitoring Rx power is particularly valuable for detecting fibre degradation, connector contamination, or link budget margin issues before they cause outages.
