• Palo Alto Compatible 40GBASE-SR-BD BiDi QSFP Transceiver Module
1 1

Blue Cable Co

PAN-QSFP-40GBASE-BIDI-BCC | Palo Alto Compatible 40GB Multi-Mode BiDi - 100m (40GBASE-SR-BD)

PAN-QSFP-40GBASE-BIDI-BCC

12 in stock

$506.00 inc. GST
$460.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The PAN-QSFP-40GBASE-BIDI-BCC is a drop-in compatible replacement for the Palo Alto PAN-QSFP-40GBASE-BIDI. This QSFP+ transceiver delivers plug-and-play 40 Gigabit Ethernet connectivity over duplex multi-mode fiber using standard LC connectors, enabling reuse of existing 10G duplex fiber infrastructure. - Compliant with IEEE 802.3ba 40GBASE-SR-BD and QSFP+ MSA SFF-8436, ensuring interoperability with standards-based 40GbE interfaces - Operates at 832-918nm wavelength range with bidirectional transmission over two 20G channels on duplex LC fiber - Reaches 100m on OM3 multi-mode fiber and 150m on OM4 multi-mode fiber - Digital optical monitoring (DOM) support provides real-time access to operational parameters including temperature, voltage, and optical power levels - Hot-swappable QSFP+ form factor with commercial temperature range (0 to 70 degrees Celsius) for standard data center environments - Enables cost-effective migration from 10G to 40G by reusing existing duplex fiber infrastructure without requiring MPO parallel fiber

Features

• IEEE 802.3ba 40GBASE-SR-BD compliance guarantees interoperability with standards-based 40 Gigabit Ethernet ports and enables direct replacement of OEM modules without firmware or configuration changes
• Bidirectional architecture transmits and receives two 20 Gbps channels simultaneously over a single duplex fiber pair using wavelength division multiplexing, reducing fiber consumption by 75 percent compared to parallel optics
• QSFP+ MSA SFF-8436 electrical and mechanical compliance ensures compatibility with any QSFP+ port supporting 40G BiDi operation, subject to vendor encoding requirements
• Commercial temperature range (0-70°C) with passive thermal design relies on host airflow, making the module suitable for standard top-of-rack and aggregation switch environments
• DOM functionality exposes real-time temperature, voltage, transmit power, and receive power via I2C interface per QSFP+ MSA specification, enabling proactive link monitoring and troubleshooting
• Duplex LC connector allows direct reuse of installed 10GBASE-SR or 10GBASE-LX duplex fiber plant for migration to 40G without re-cabling or converting to MPO
• Hot-swappable operation permits field installation and replacement without powering down the host platform, minimizing service disruption during upgrades or maintenance

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: PAN-QSFP-40GBASE-BIDI-BCC
Compatible Replacement For: PAN-QSFP-40GBASE-BIDI
Compatibility: Palo Alto compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: QSFP+
Data Rate: 40 Gbps (aggregate)
Wavelength: 832-918nm (bidirectional)
Fibre Type: Multi-mode (OM3/OM4)
Connector Type: Duplex LC
DOM Support: Yes (digital optical monitoring)
Standards: IEEE 802.3ba 40GBASE-SR-BD, QSFP+ MSA SFF-8436
Max Reach: 100m on OM3 MMF, 150m on OM4 MMF
Operating Temperature: 0 to 70°C (commercial)

FAQs

Q: Will this work in place of the Palo Alto PAN-QSFP-40GBASE-BIDI?
A: Yes. This transceiver is a direct replacement for the PAN-QSFP-40GBASE-BIDI. It conforms to the same IEEE 802.3ba 40GBASE-SR-BD standard, uses the same QSFP+ form factor, and operates at the same 40 Gbps data rate over 832-918nm bidirectional wavelengths. The module is plug-and-play compatible with Palo Alto platforms that list the PAN-QSFP-40GBASE-BIDI as a supported transceiver.

Q: Which Palo Alto platforms support this transceiver?
A: This module is compatible with any Palo Alto firewall or network platform featuring QSFP+ ports that support 40GBASE-SR-BD BiDi operation. Compatibility depends on the port supporting IEEE 802.3ba 40 Gigabit Ethernet with bidirectional multi-mode fiber transceivers. Consult your platform hardware compatibility list or contact Blue Cable Co to confirm support for your specific model.

Q: What fiber type is required and why does the BiDi architecture matter?
A: This transceiver requires laser-optimized OM3 or OM4 multi-mode duplex fiber with LC connectors. The BiDi design uses two wavelengths in the 832-918nm range, with each fiber carrying bidirectional traffic via wavelength division multiplexing. This allows 40G transmission over a standard two-fiber duplex cable instead of the eight fibers required by 40GBASE-SR4 with MPO connectors, enabling reuse of existing 10G fiber infrastructure.

Q: Does this module require a matched pair at both ends of the link?
A: Yes. BiDi transceivers operate in complementary pairs. One transceiver transmits at the lower wavelength and receives at the upper wavelength, while the opposite end does the inverse. Both ends must be 40GBASE-SR-BD BiDi modules with matched wavelength pairs in the 832-918nm range. Mixing BiDi with SR4 or other 40G optics on the same link will result in link failure.

Q: What is the optical power budget and can I use patch panels?
A: 40GBASE-SR-BD BiDi modules typically provide a 2 dB minimum optical power budget, supporting 100m on OM3 and 150m on OM4 under controlled conditions. This budget accounts for fiber attenuation and a limited number of mated LC connector pairs. Adding patch panels increases insertion loss and may reduce effective reach. For links approaching maximum distance or using multiple patch points, verify total link loss remains within the module power budget using an optical loss test set.
