NVIDIA

NVIDIA 980-9I559-00N002 | LinkX NDR SMF Fibre Cable, MPO12 APC to APC, 2m

SKU:980-9I559-00N002

$119.00 USD
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This NVIDIA LinkX passive single-mode fibre trunk cable is terminated with MPO-12 APC connectors on both ends and measures 2 m in length. It is built for NDR InfiniBand and 400GbE links between DR4 and PSM4-class transceivers, and is validated for use with ConnectX-7, BlueField and Quantum-2 platforms. The APC angled polish reduces back-reflection, making it well suited to high-speed data centre and AI cluster interconnects.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Validated and supported NDR cable listed in NVIDIA networking documentation
- APC endface with 8-degree angled polish to reduce back-reflection
- Interconnects single-mode OSFP and QSFP112 DR4/PSM4-type transceivers
- Suitable for both InfiniBand and Ethernet links
- Passive design with no power requirement

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Find the Right Cable

Technical Specifications

- Part number: 980-9I559-00N002 (model MFP7E30-N002)
- Fibre type: single-mode (SMF/OS2 9/125 µm)
- Connectors: MPO-12 APC to MPO-12 APC
- Length: 2 m
- Fibre count: 12
- Cable class: NDR InfiniBand / 400GbE
- Validated for ConnectX-7, BlueField and Quantum-2

FAQs

Q: Is this cable single-mode or multimode?
A: It is a single-mode (SMF/OS2 9/125 µm) cable and must be used with single-mode transceivers such as DR4 or PSM4-class optics.

Q: What connectors does this cable use?
A: Both ends are terminated with MPO-12 connectors with an APC (angled physical contact) polish.

Q: Which platforms is this cable validated for?
A: It is listed as a validated NDR cable for NVIDIA ConnectX-7, BlueField and Quantum-2 platforms.

Q: Can I mix APC and UPC connectors with this cable?
A: No. APC and UPC endfaces should not be mated. Use this cable only with transceivers and panels that have MPO-12 APC interfaces.

Q: What link speeds is this cable intended for?
A: It is intended for NDR InfiniBand and 400GbE links using DR4-class single-mode optics.
