• Juniper Compatible 10G BiDi SFP+ Transceiver Module 10km
1 1

Blue Cable Co

JNP-SFP-10G-BX10D-BCC | Juniper Compatible 10GB BiDi Transceiver - 10km (10GBASE-BX-D)

JNP-SFP-10G-BX10D-BCC

6 in stock

$89.10 inc. GST
$81.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The JNP-SFP-10G-BX10D-BCC is a drop-in compatible replacement for the Juniper JNP-SFP-10G-BX10D. This 10GBASE-BX-D BiDi transceiver operates plug-and-play in Juniper SFP+ ports, transmitting and receiving over a single strand of single-mode fibre. - 10GBASE-BX-D standard compliance ensures interoperability with any 10G BiDi-capable SFP+ port - SFP+ form factor, 10Gbps data rate, 1330nm Tx / 1270nm Rx wavelength pair, up to 10km over OS2 single-mode fibre - LC simplex connector with bidirectional transmission, saving 50% fibre infrastructure compared to duplex links - Digital diagnostics monitoring (DDM) via SFF-8472 interface for real-time optical power, temperature, bias current, and voltage parameters - Must be used in matched pairs with a complementary 1270nm Tx / 1330nm Rx transceiver at the opposite end

Features

• 10GBASE-BX-D standard defines the BiDi wavelength pairing and guarantees interoperability with any standards-compliant 10G BiDi port, eliminating vendor lock-in for single-fibre 10G links
• Bidirectional WDM technology transmits 1330nm and receives 1270nm simultaneously on one fibre strand, doubling transmission capacity without installing new fibre runs
• SFF-8472 digital diagnostics interface exposes five real-time parameters: transmit power, receive power, laser bias current, supply voltage, and module temperature for proactive link troubleshooting
• Hot-swappable SFP+ form factor supports installation and removal without powering down the host platform, minimising service interruption during maintenance or upgrades
• LC simplex connector design requires only one fibre strand per link direction, reducing patch panel density and simplifying cable management in high-port-count deployments
• Must be deployed in wavelength-matched pairs: this -D variant (1330nm Tx / 1270nm Rx) pairs with a -U variant (1270nm Tx / 1330nm Rx) at the opposite end of the fibre span
• Low power consumption and SFP+ MSA compliance ensure compatibility across Juniper switches, routers, and interface modules with 10G SFP+ slots

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Also Known As

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: JNP-SFP-10G-BX10D-BCC
Compatible Replacement For: JNP-SFP-10G-BX10D
Compatibility: Juniper compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10Gbps
Standard: 10GBASE-BX-D
Wavelength: 1330nm Tx / 1270nm Rx
Fibre Type: Single-mode (SMF)
Connector Type: LC Simplex
Max Reach: Up to 10km over OS2 single-mode fibre
DOM Support: Yes (SFF-8472 compliant)
Operating Temperature: 0°C to 70°C (commercial)

Also Known As

740-066990

FAQs

Q: Will this work in place of the Juniper JNP-SFP-10G-BX10D?
A: Yes. This transceiver is a plug-and-play replacement for the JNP-SFP-10G-BX10D. It matches the SFP+ form factor, 10Gbps data rate, 1330nm Tx / 1270nm Rx wavelength pair, and 10GBASE-BX-D standard, ensuring transparent operation in any Juniper platform that supports the original part number.

Q: Which Juniper platforms support this transceiver?
A: This transceiver works in any Juniper switch, router, or interface module with a 10G SFP+ slot that supports 10GBASE-BX operation. This includes platforms across the EX, QFX, MX, and PTX families. Verify that your specific platform and software release support BiDi optics by checking the Juniper Hardware Compatibility Tool or your platform datasheet.

Q: What is the -D designation and why does wavelength pairing matter?
A: The -D suffix indicates this is the downstream variant, transmitting at 1330nm and receiving at 1270nm. BiDi transceivers use WDM to send and receive on the same fibre, so the wavelengths at each end must be reversed. This -D module must be paired with a -U upstream module (1270nm Tx / 1330nm Rx) at the opposite end. Mismatched wavelengths will result in no link.

Q: What fibre type and loss budget does this transceiver require?
A: This transceiver requires OS2 single-mode fibre (G.652 or better). The 10km reach specification assumes a maximum link loss budget of approximately 6.2 dB, which includes fibre attenuation, splice loss, and connector loss. Actual reach depends on fibre quality, number of splices, and patch cord condition. For spans approaching 10km, perform an optical loss test to confirm the link budget.

Q: Can I use this transceiver in a 1G or 2.5G application?
A: No. This is a dedicated 10G transceiver designed for 10GBASE-BX-D operation at 10.3125 Gbps line rate. It does not support rate adaptation to 1G or 2.5G. For multi-rate BiDi links, select a transceiver explicitly rated for the required speeds, or use separate transceivers for each data rate.
