• Sophos Compatible 10GBASE-LR SFP+ Transceiver Module with Blue Logo
1 1

Blue Cable Co

ITFZTCHLR-BCC | Sophos Compatible 10GB Single-Mode 10km (10GBASE-LR)

ITFZTCHLR-BCC

43 in stock

$90.20 inc. GST
$82.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ITFZTCHLR-BCC is a drop-in compatible replacement for the Sophos ITFZTCHLR. This SFP+ transceiver provides plug-and-play compatibility with Sophos UTM, SG, and XG series appliances equipped with SFP+ ports. - IEEE 802.3ae 10GBASE-LR compliance guarantees interoperability with standards-compliant 10 Gigabit Ethernet equipment - SFP+ form factor, 10 Gbps data rate, 1310nm wavelength, 10km reach over single-mode fibre with duplex LC connector - Digital diagnostics monitoring (DOM) support via SFF-8472 interface for real-time parameter access including transmit power, receive power, temperature, and voltage - Compliant with SFF-8431 and SFF-8432 multi-source agreements ensuring mechanical and electrical compatibility - Operating temperature range of 0 to 70°C for commercial deployment environments - Hot-pluggable design allows installation and removal without system shutdown

Features

• IEEE 802.3ae 10GBASE-LR defines transmitter output power, receiver sensitivity, and link budget to ensure predictable optical performance over single-mode fibre infrastructure up to 10km
• SFF-8431 and SFF-8432 compliance covers high-speed serial electrical interface, mechanical dimensions, connector requirements, and thermal characteristics for consistent host compatibility
• 1310nm wavelength operation over single-mode OS2 fibre using uncooled DFB laser transmitter and limiting electrical receiver interface for stable long-reach transmission
• Digital diagnostics (DOM) accessible via I2C interface per SFF-8472, providing real-time monitoring of optical power levels, temperature, bias current, and supply voltage for proactive link management
• Hot-pluggable SFP+ footprint with duplex LC connector enables module installation and replacement without interrupting adjacent ports or system operation
• Power dissipation under 1W from single 3.3V supply reduces thermal load in multi-port deployments and lowers total energy consumption in firewall and security appliance environments

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: ITFZTCHLR-BCC
Compatible Replacement For: ITFZTCHLR
Compatibility: Sophos compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP+
Data Rate: 10 Gbps
Standards: IEEE 802.3ae 10GBASE-LR, SFF-8431, SFF-8432
Wavelength: 1310nm
Fibre Type: Single-mode (SMF)
Connector Type: Duplex LC
Max Reach: Up to 10km (per datasheet, subject to fibre and link conditions)
DOM Support: Yes (SFF-8472)
Operating Temperature: 0 to 70°C (commercial)
Power Consumption: <1W

FAQs

Q: Will this work in place of the Sophos ITFZTCHLR?
A: Yes. The ITFZTCHLR-BCC provides drop-in replacement compatibility with the Sophos ITFZTCHLR based on IEEE 802.3ae 10GBASE-LR standard compliance, matching form factor (SFP+), data rate (10 Gbps), wavelength (1310nm), and fibre type (single-mode). It is plug-and-play compatible with Sophos platforms.

Q: Which Sophos platforms support this transceiver?
A: This transceiver is compatible with Sophos UTM, SG, and XG series appliances equipped with SFP+ ports, including those using optional Flexi Port modules with 10GbE SFP+ slots. Any Sophos platform with a standards-compliant SFP+ interface supporting 10GBASE-LR will accept this module.

Q: What type of fibre cable is required and what reach can I expect?
A: This module requires single-mode fibre (OS2 recommended) with duplex LC connectors. Maximum reach is 10km per IEEE 802.3ae specifications. Actual distance depends on fibre quality, connector loss, splice loss, and total link budget. The module provides sufficient optical budget for typical 10km spans with standard OS2 fibre and clean connectors.

Q: How do I access DOM diagnostics on Sophos appliances?
A: DOM parameters are accessible via the Sophos CLI or web interface depending on firmware version. The module exposes transmit power, receive power, temperature, voltage, and laser bias current per SFF-8472. Check your Sophos documentation for interface-specific commands to retrieve transceiver diagnostics for link health monitoring.

Q: Can this transceiver operate in extended temperature environments?
A: This module is rated for commercial temperature range (0 to 70°C). It is not suitable for industrial environments requiring operation below 0°C or above 70°C. For outdoor cabinets, telecom huts, or other temperature-extreme deployments, verify ambient conditions remain within the commercial operating range or select an industrial-grade variant.
